2.1.4 RWF40, LMV52, RM7800, LMV36, PD765, RWF55, LMV2_3 or YB110

Refer to the Boiler's instruction manual for password and menu navigation instructions to make the
following settings:
Table 2-3: RWF40, LMV52, RM7800, LMV36, PD765, RWF55, LMV2_3 or YB110 Com.
Settings

2.1.5 Settings for Conductor Sequencing Panel

On Conductor, from the Modbus/BACnet Setup menu set the following:
Table 2-4: Conductor Communication Settings
EMS Communication
Conductor RS485-1 Address
EMS Baud Rate
•
To edit Communication Parameters, select "Menu" from the home screen.
•
On the "Main Menu" select "EMS Interface" and select "Modbus/BACnet Setup".
•
Enter the password by pressing the lock icon.
•
Press the line for each parameter and enter the new selection.
•
Once all parameters have been set to the correct selection, cycle power to the panel to enact the
changes.
Page 8 of 97
Model
RWF55, YB110
RWF40, RM7800,
LMV36, LMV52,
PD765, LMV2_3
All
Parameter
EMS Parity
Port Setting Selection
Baud Rate 38400
Baud Rate 19200
Protocol Modbus RTU
Parity None
Data Bits 8
Stop Bits 1
Selection
Modbus
Between 1 and 20
38400
None
PN: 106417-05
