12.13 Conductor Sequencing Panel

Table 12-15: Conductor Sequencing Panel LonWorks Points List
Point Name
Plant_load
EMS_Enable
EMS_Setpoint
Firing_Rate
Active_Setpoint
Master_SP_Source
Status
Priority
Lead
SYSTEM_SUPPLY
SYSTEM_RETURN
OUTDOOR_AIR
UAI5_EMS_SETPOINT
UAI7_PUMP_FEEDBACK
STEAM_PRESSURE
BLR_A_SHELL
BLR_B_SHELL
BLR_C_SHELL
BLR_D_SHELL
UDO1_CONFIGURABLE
UDO2_ALARM
UDO7_BLR_D_ISOLATION_VALVE
UDO8_PUMP_A
UDO9_BLR_A_ISOLATION_VALVE
UDO10_BLR_B_ISOLATION_VALVE
UDO11_BLR_C_ISOLATION_VALVE
UDO12_PUMP_B
ALR_Press_High
ALR_Press_Low
ALR_Temp_High
ALR_Temp_Low
ALR_Return_Temp_Low
ALR_Pump_A_Fault
ALR_Pump_B_Fault
ALR_Shell_1_High
ALR_Shell_2_High
ALR_Shell_3_High
ALR_Shell_4_High
BLR1_Supply
BLR1_Return
BLR1_Stack
BLR1_CH_Mod_Rate
BLR1_Rate_Commanded
BLR1_CH_Mod_Stat
BLR1_General_Alarm
BLR1_Boiler_Pump
BLR1_System_Pump
BLR1_Pump_Status
BLR1_Flame
BLR1_State
BLR1_Ann_Lockout
BLR1_Ann_Hold
ALR_BLR1SupplyHigh
Page 77 of 97
Lon Name
nvoPlant_Ld_XXX SNVT_count_f
nvi/nvoEMS_Enbl_XXX SNVT_switch
nvi/nvoEMS_SP_XXX SNVT_temp_p
nvoFir_Rate_XXX SNVT_lev_percent
nvoAct_SP_XXX SNVT_temp_p
nvoMstrSPSrc_XXX SNVT_count_f
nvoStatus_XXX SNVT_count_f
nvoPriority_XXX SNVT_count_f
nvoLead_XXX SNVT_count_f
nvoSys_Sup_XXX SNVT_temp_p
nvoSys_Ret_XXX SNVT_temp_p
nvoOtdr_Air_XXX SNVT_temp_p
nvoAI5EMS_SP_XXX SNVT_temp_p
nvoPmp_Fdbk_XXX SNVT_lev_percent
nvoStm_Prs_XXX SNVT_count_f
nvoBlrAShl_XXX SNVT_temp_p
nvoBlrBShl_XXX SNVT_temp_p
nvoBlrCShl_XXX SNVT_temp_p
nvoBlrDShl_XXX SNVT_temp_p
nvoUDO1_Cnfg_XXX SNVT_count_f
nvoUDO2_Alm_XXX SNVT_count_f
voBlDIsoVlv_XXX SNVT_switch
nvoPmp_A_XXX SNVT_switch
nvoBlAIsoVlv_XXX SNVT_switch
nvoBlBIsoVlv_XXX SNVT_switch
nvoBlCIsoVlv_XXX SNVT_switch
nvoPmp_B_XXX SNVT_switch
nvoALR_PrsHi_XXX SNVT_switch
nvoALR_PrsLo_XXX SNVT_switch
nvoALR_TmpHi_XXX SNVT_switch
nvoALR_TmpLo_XXX SNVT_switch
nvoALRRtTpLo_XXX SNVT_switch
nvoALRPmAFlt_XXX SNVT_switch
nvoALRPmBFlt_XXX SNVT_switch
nvoALR_Sh1Hi_XXX SNVT_switch
nvoALR_Sh2Hi_XXX SNVT_switch
nvoALR_Sh3Hi_XXX SNVT_switch
nvoALR_Sh4Hi_XXX SNVT_switch
nvoB1_Sup_XXX SNVT_temp_p
nvoB1_Ret_XXX SNVT_temp_p
nvoB1_Stk_XXX SNVT_temp_p
nvoB1_CHMdRt_XXX SNVT_lev_percent
nvoB1_RteCmd_XXX SNVT_lev_percent
nvoB1_CHMdSt_XXX SNVT_switch
nvoB1_GenAlm_XXX SNVT_switch
nvoB1_BlrPmp_XXX SNVT_switch
nvoB1_SysPmp_XXX SNVT_switch
nvoB1_PmpSta_XXX SNVT_switch
nvoB1_Flame_XXX SNVT_count_f
nvoB1_State_XXX SNVT_count_f
nvoB1_AnnLck_XXX SNVT_count_f
nvoB1_AnnHld_XXX SNVT_count_f
nvoALRB1SpHi_XXX SNVT_switch
Lon SNVT Type
