FieldServer LonWorks ProtoNode Instruction Manual page 59

Active LL Setpoint
Supply Sensor
Return Sensor
Header Sensor
Stack Sensor
Outdoor Sensor
4-20 mA Rem Control Input
Fan Speed
Flame Signal
Burner Control State
Lockout Code
Hold Code
Page 59 of 97
-40 F (-40°C) to 266 F (130°C)
Setpoint determined by LL
setpoint source (register 162).
-40 F (-40°C) to 266 F (130°C)
-40 F (-40°C) to 266 F (130°C)
-40 F (-40°C) to 266 F (130°C)
-40 F (-40°C) to 266 F (130°C)
-40 F (-40°C) to 266 F (130°C)
mA value for S2 (J8-6)
parameter selectable as
(remote set point) & (remote
modulation)
Speed of the combustion air
blower in rpm
0.01V or 0.01μA precision
(0.00-50.00V)
0 Initiate
1 Standby Delay
2 Standby
3 Safe Startup
4 Prepurge - Drive to
Purge Rate
Prepurge – Measured
5
Purge Time
Prepurge – Drive to
6
Lightoff Rate
7 Preignition Test
8 Preignition Time
9 Pilot Flame Establishing
Period
10 Main Flame Establishing
Period
11 Direct Burner Ignition
12 Run
13 Postpurge
14 Lockout
Reasons for burner lockout
0 No lockout,
4 Supply high limit
5 DHW high limit
6 Stack High limit
12 Flame detected out of
sequence
18 Lightoff rate proving
failed
19 Purge rate proving failed
20 Invalid Safety
Parameters
21 Invalid Modulation
Parameter
22 Safety data verification
needed
23 24VAC voltage low/high
24 Fuel Valve Error
25 Hardware Fault
26 Internal Fault
27 Ignition Failure
Reason for burner hold
0 None
1 Anti short cycle
2 Boiler Safety Limit Open
3 Boiler Safety Limit
Open, (ILK Off)
7 Return sensor fault
8 Supply sensor fault
9 DHW sensor fault
10 Stack sensor fault
11 Ignition failure
13 Flame rod shorted to
ground
nvoAct_LL_SP_XXX
410,018
nvoSupSensor_XXX
410,007
nvoRetSensor_XXX
410,011
nvoHdrSensor_XXX
410,013
nvoStkSensor_XXX
410,014
nvoOtdrSensr_XXX
410,170
nvoRemCtrlIn_XXX
400,015
nvoFan_Speed_XXX
400,009
nvoFlmSig_XXX
400,010
nvoBrnCtrlSt_XXX
400,033
nvoLockotCod_XXX
410,034
nvoHoldCode_XXX
410,040
SNVT_temp_p
SNVT_temp_p
SNVT_temp_p
SNVT_temp_p
SNVT_temp_p
SNVT_temp_p
SNVT_count_f
SNVT_count_f
SNVT_count_f
SNVT_count_f
SNVT_count_f
SNVT_count_f
PN: 106417-05
