Table 2-5: ProtoNode Auto-Discovery Settings
LonWorks ProtoNode
S3 DIP Switch Auto-Discovery Mode S3
Auto-Discovery ON – Build New Configuration
On
Auto-Discover OFF – Load Current Configuration
Off
NOTICE: Initial Auto Discovery Cycle All boilers MUST be POWERED and CONNECTED to the
-
ProtoNode before cycling power to the ProtoNode. The ProtoNode will auto discover only connected
boilers. If a boiler is connected after the ProtoNode has completed auto discovery it will not "find" the new
boiler.

2.2.3 Commission the ProtoNode for LonWorks

This needs to be done by the LonWorks administrator use a LonWorks Commissioning tool. (See Section
6.6)
Page 10 of 97 PN: 106417-05
