Roller shutter
sensor
Installation guide
INTRODUCTION
Flush contact for the protection of blinds and rolling shutters. The device is the safest in terms of
construction and safety that the market can offer. The actuation of the microswitch occurs through a
linkage that closes and opens the microswitch infallibly avoiding the stall condition that normally can occur
in the absence of this arrangement. The internal cam is made of polycarbonate, the thread-sliding roller is
made of Delrin and slides on a roller in lapped steel. With connection terminals for connection of the two
cables.
TECHNICAL DATA
•
Detection system: Omron microswitch with gold contacts
•
Type of contact: NC (Normally closed)
•
Pulse time: 4 ms ÷ 6 ms
•
Body Material: ABS
•
Cam material: polycarbonate
•
Roller material: Derlin on steel
•
Cable material: nylon
•
Connection: 2 terminals
•
Useful length of the lanyard: 2,9 m ÷ 3,1 m
•
Operating temperature: - 10°C ~ + 55°C
•
Dimensions: 109 x 90 x 14 mm
code KSI5004000.300
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ksenia KSI5004000.300
Summary of Contents for Ksenia KSI5004000.300
- Page 1 Roller shutter sensor Installation guide code KSI5004000.300 INTRODUCTION Flush contact for the protection of blinds and rolling shutters. The device is the safest in terms of construction and safety that the market can offer. The actuation of the microswitch occurs through a linkage that closes and opens the microswitch infallibly avoiding the stall condition that normally can occur in the absence of this arrangement.
- Page 2 INSTALLATION Place the sensor (1) inside the box (2) and fix the end of the cord in the lower part of the roller shutter. LEGEND 1. Roller shutter sensor 2. Roller shutter box CONNECTION Do not connect the device to the control panel mother board or duo inputs, only connect the device on inputs that manage the fast zones (auxi module, auxi-10 module, poli magnetic contact or ergo keypad).
- Page 3 Connection with auxi expansion module LEGEND 1. roller shutter sensor 2. auxi module (M1...M5 programmed as inputs) Connection with auxi-10 expansion module LEGEND 1. roller shutter sensor 2. auxi-10 module (i1...i5 inputs) Connection with ergo keypad LEGEND 1. roller shutter sensor 2.
- Page 4 Test procedures depends on the system configuration. Ask to the installer for the procedures to be followed. Ksenia Security srl shall not be responsible for damage arising from improper installation or maintenance by unauthorized personnel.
