Ksenia unum-X ST wls Quick Start Manual

I rilevatori di movimento wireless unum-X ST wls con rilevamento PIR e unum-X DT X5/X8 wls a doppia tecnologia PIR
e a microonde, sono sensori professionali senza fili che comunicano con la centrale lares 4.0 su banda radio a 868 MHz; garantiscono
il più alto grado di affidabilità nella rilevazione del movimento con infrarossi passivi (PIR), microonda X5 e X8 e immunità da animali
domestici; inoltre la lente Fresnel di tipo sferico è ruotabile, offrendo la possibilità di ottenere un'area di rilevamento di tipo stretto
("narrow") per proteggere pareti, finestre, corridoi, ecc., contrapposto all'area di rilevamento, di base, di tipo ampio ("wide").
unum-X ST wls indoor motion detectors with PIR and unum-X DT X5/X8 wls dual technology with PIR and microwave
detection, are wireless professional detectors, in compliance with the wireless bidirectional 868 MHz protocol used by Ksenia Security
control panels; they guarantee the highest degree of reliability in the detection of the movement using passive infrared (PIR),
microwave X5 and X8 and Pet immunity; and more, the Fresnel spherical lens can be rotated to obtain a narrow detection area, useful
to protect walls, windows, corridors, etc., opposed to the default wide detection area.
Les détecteurs de mouvement intérieurs de la série unum-X ST wls avec détection PIR et unum-X DT X5/X8 wls à double
technologie avec détection PIR et micro-ondes, sont des capteurs sans fil professionnels qui communiquent avec la plateforme lares
4.0 sur une bande radio à 868 MHz ; garantissent le plus haut degré de fiabilité dans la détection de mouvement avec l'infrarouge
passif (PIR), les micro-ondes X5 et X8 et l'immunité aux animaux ; de plus, la lentille Fresnel sphérique peut être tournée, offrant la
possibilité d'obtenir une zone de détection étroite pour protéger les murs, les fenêtres, les couloirs, etc., par opposition à la zone de
détection de base de type large.
SPECIFICHE TECNICHE - TECHNICAL SPECIFICATIONS - SPÉCIFICATIONS TECHNIQUES
Wireless communication
Power input
Consumption
Detection method
Flip lens 180°
Coverage: Wide (default)
Narrow (MW disabled)
Microwave frequency
Microwave function
Detection zones
Detectable speed
Inhibition time (programmable)
PIR Sensitivity
LED color
Mounting height
SMDA logic
Pet immunity
Cover tamper
Wall tamper
Warm up period
Mounting
Battery life(*)
Voltage for battery fault
Dimensions (WxDxH)
Weight (without battery)
Operating temperature
Environmental humidity
(*)note: to be compliant with the standard EN 50131-1 and T031 set the parameter "Always active" to OFF
Specifiche tecniche, aspetto, funzionalità ed altre caratteristiche del prodotto, possono cambiare senza preavviso.
Technical specifications, appearance, functionality and other product characteristics may change without notice.
Spécification techniques, l'apparence, la fonctionnalité et les autres caractéristiques du produit peuvent changer sans préavis.
unum-X ST - DT wireless
KSI5201001.300 unum-X ST wls - Grado 2
KSI5202001.300 unum-X DT X5 wls - Grade 2
KSI5202001.301 unum-X DT X8 wls - Grade 2
Rilevatore di movimento per interni (wls)
Indoor Motion detector (wls)
Detecteur de mouvement intérieur (sans fil)
INTRODUZIONE - INTRODUCTION - INTRODUCTION
KSI5201001.300
3V lithium battery - Panasonic CR123A recommended
max 26 mA (STBY 0.015 mA)
PIR
-
-
from 5 to 180 seconds (to be compliant with the standard EN 50131-1 and T031)
1.6°C at 0.6 m/s at 2.4 m mounting height
1 color LED (RED), Stand-by (OFF), Alarm/Tamper (ON),
Warm up (blinks for approx. 60 seconds), Walktest end (fast blinking for 5 seconds)
2.0 to 3.0 m (2.4 m recommended)
(PIR with low sensitivity, up to 30 cm of the animal's height)
Wall, Corner (with optional brackets: Wall, Corner, Celling )
4 years
H: 129.2 x W: 61.5 x D: 50.9 mm
94 g
KSI5202001.300 - X5
868.5 MHz
max 50 mA (peak) (stand-by 0.015 mA)
Fresnel lens
12 m 85°
18 m 5°
X5 : 10.525 GHz
When using the narrow lens, MW function will be disabled
Wide : 76 zones
Narrow : 12 zones
0.3~2.0 m/s
60 seconds (approx.)
2-3 years
2.5 V (approx.)
from -10°C to +40°C
95% max.
KSI520200.301 - X8
PIR & MW
X8 : 10.587 GHz
108 g
