Summary of Contents for GlammFire Crea7ion Plus ARCHIMEDES
- Page 1 INSTRUCTIONS MANUAL ARCHIMEDES...
- Page 2 PAG./2 Thank you for purchasing a GlammFire product. In order to activate your 2-year GlammFire warranty, please register your GlammFire product at www.GlammFire.com/pt/sobre/garantia or complete your warranty card and send it to us along with a purchase copy, to our address, within 30 days after the purchase.
-
Page 3: Table Of Contents
GlammFire. PAG./3 INDEX 1—Supplied Material 2—Components 3—Safety Instructions 3.1—Ventilation 3.2—Cautions 4—Fuel 4.1—Bioethanol – The adequate fuel 5—Installlation 5.1—Flammable Materials 5.2—Materials: Stone/ Metal/ Ceramics 6—Installation Procedure 7—Maintenance 8—Overrall Dimensions 9—After—Sales Service 10—Warranty... -
Page 4: 1-Supplied Material
GlammFire. PAG./4 Please read this Instructions Manual carefully before using your decorative fireplace. It contains important operating and maintenance instructions that should be followed correctly in order to ensure a durable use of your decorative fireplace. All presented cautions and warnings must be respected. Keep this manual for future reference. -
Page 5: 3-Safety Instructions
3.2—Cautions: GlammFire is concerned about your safety, therefore we have taken all necessary consideration for conception, fabrication, assembly and transport, to ensure perfect functioning. We therefore ask you to thoroughly follow our instructions for assembly, use and maintenance. - Page 6 GlammFire. PAG./6 -If you spill bioethanol onto the floor, you must absorb it with a cloth, and then clean with a wet cloth, to avoid ignition outsider the combustion fire line and stains on the floor; -In case you spill bioethanol in the fireplace clean it immediately with a wet cloth, to avoid ignition outside the combustion fire line and damages to the finishing of the fireplace (paint, lacquers, leathees, amongst others);...
-
Page 7: 4-Fuel
GlammFire. PAG./7 4 - Fuel 4.1—Bioethanol – The adequate fuel GlammFire fireplaces are designed to work with quality bioethanol, fully tested. Only this fuel en- sures clean and efficient. -Higher probability of malfunction; -Reduction in durability of the system; -Incomplete and inefficient combustion;... -
Page 8: 5-Installlation
GlammFire. PAG./8 5—Installation 5.1—Flammable materials -Do not place flammable materials near the fireplace, within 1m; -Racks or shelves should be distant 1m from the combustion fire line; 5.2—Materials: stone/metal/ceramics A - 150 mm; B - 150 mm; ... -
Page 9: 6-Installation Procedure
GlammFire. PAG./9 6—Installation Procedures For this procedure you will need at list two people. To start the mounting of the Archimedes fireplace you should make sure that you are putting it on a place where the safety measures are being respected, as described in the previous page. The next step is to check if the base doesn´t balance which can be made through the leveler feet of the inferior... - Page 10 GlammFire. PAG./10 Proceed with the installation of the base with the intermediate body, where the pin( a) and the center tube (b) fit in the hole present in the intermediate body (holes c (anyone of the holes marked with a triangle) and d (center hole, respectively). With the base on the ground, pick up the central body and while landing it make sure the pin and the tube are placed in the right place (e), staying has represented in the image (f).
- Page 11 GlammFire. PAG./11...
- Page 12 GlammFire. PAG./12 Next, pick the superior cone (b) and put it on top of the structure that is already set (c). Make sure that the hole that exists on the superior cone has a nut (e) that matches with a free hole existent in the intermediate body.
- Page 13 GlammFire. PAG./13 Then place the EvoPlus Fire Round burner using the handle supplied to assist in its han- dling (see burner’s instructions manual, chapter: Installation Procedures). To finalize you only need to apply the glass.
-
Page 14: 7-Maintenance
GlammFire. PAG./14 7—Maintenance -The combustion fire line should be cleaned regularly using a damp cloth with bioethanol; -The more persistent marks can be removed using a soft cloth moistened in bioethanol; -Never use chemicals not suitable for cleaning stainless steel;... -
Page 15: 8-Overrall Dimensions
GlammFire. PAG./15 8—Overall Dimensions... -
Page 16: 9-After-Sales Service
In order to activate your GlammFire 2 year warranty, please register your new GlammFire product at www.GlammFire.com/en/about/warranty or complete your warranty card and return it to us, along with a copy of the proof of purchase, at our address within 30 days of purchase. - Page 17 GlammFire. PAG./17 Equipment: Guarentee Beneficiary: Version: Adress: Constroller: Tel.: Availability date: Local…………………………………………..Date……………………….. Signature: Serial and Guarantee numbers: Distributor code: Name and Adress of the Distributor:...
- Page 18 Focusing on the reduction of energy consumption, raw materials, natural resources and quantity of waste generated, GlammFire follows the policy of the 4R’s (Reduce, Reuse, Recycle and Recover). Thus GlammFire has in mind the use of long lasting products as well as reusable and recyclable products.
- Page 19 GlammFire. PAG./19...
- Page 20 Recuperadores Pachinha Lda. Zona Industrial da Lagoa, Lote G1 4950-850 CORTES - MONÇÃO PORTUGAL Tel(+351) 251 654 800 Fax(+351) 251 654 801 info@glammfire.com www.glammfire.com PT13484-A...
