INSTRUCTIONS MANUAL
THALES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Crea7ion EvoPlus Thales and is the answer not in the manual?

Questions and answers

Related Manuals for GlammFire Crea7ion EvoPlus Thales

Summary of Contents for GlammFire Crea7ion EvoPlus Thales

  • Page 1 INSTRUCTIONS MANUAL THALES...
  • Page 2 GlammFire. PAG./2 Thank you for purchasing a GlammFire product. In order to activate your 2-year GlammFire warranty, please register your GlammFire product at www.GlammFire.com/pt/sobre/garantia or complete your warranty card and send it to us along with a purchase copy, to our address, within 30 days after the purchase.

  • Page 3: Table Of Contents

    GlammFire. PAG./3 INDEX 1—Material Supplied 2—Components 3—Safety Instructions 3.1—Ventilation 3.2—Cautions 4—Fuel 4.1—Bioethanol – The adequate fuel 5—Installation 5.1—Flammable material 5.2—Materials: stone/metal/ceramics 6—Installation Procedures 7—Extension of tube (option) 8—Maintenance 9—Overall Dimensions 10—After-Sales Service 11—Warranty...

  • Page 4: 1-Material Supplied

    GlammFire. PAG./4 Please read this Instructions Manual carefully before using your decorative fireplace. It contains important operating and maintenance instructions, that should be followed correctly in order to ensure a durable use of your decorative fireplace. All presented cautions and warnings must be respected.

  • Page 5: 3-Safety Instructions

    3.2—Cautions GlammFire is concerned about your safety, therefore we have taken all necessary consideration for conception, fabri- cation, assembly and transport, to ensure perfect functioning. We therefore ask you to thoroughly follow our instructions for assembly, use and maintenance.
  • Page 6 GlammFire. PAG./6 Do not use water to extinguish the fire;  Do not use chemical products to clean the fireplace, as they may damage the materials. When in doubt contact an  authorized dealer; After flame cutting may remain small residual flames at the point of fuel inlet for approximately 2 to 10 minutes. At ...

  • Page 7: 4-Fuel

    PAG./7 4—Fuel 4.1—Bioethanol – The adequate fuel GlammFire fireplaces are designed to work with quality bioethanol, fully tested. Only this fuel ensures clean and  efficient combustion. Fuel with less or inappropriate quality may lead to: Higher probability of malfunction;...

  • Page 8: 5-Installation

    GlammFire. PAG./8 5—Installation 5.1—Flammable material Do not place flammable materials near the fireplace, within 1m;  Racks or shelves should be distant 1m from the combustion fire line;  5.2—Materials: stone/metal/ceramics A - 150 mm;  B - 150 mm;...

  • Page 9: 6-Installation Procedures

    GlammFire. PAG./9 6—Instalação At least two people are required for this procedure. Thales is a fireplace designed to be installed in places with a ceiling height between 2500 and 2700mm having an available regulation of 200mm. It should be at and it should be at a distance from the floor to the bottom of the fireplace of 300mm having an available regulation of 200mm.
  • Page 10 GlammFire. PAG./10 Assemble the body by placing the tube (D) so that it engages the top of the structure (E). It is important to follow the order of the components: washer (H), 3 x spacers (I) inside the bearing (J), washer (H), nut (G) and locknut (G). The nuts are tightened with the supplied wrench (F), make sure that the first nut is tightened allowing the assembly to rotate.
  • Page 11 GlammFire. PAG./11 After the part (K) is fixed to the ceiling and the set (L) is completely assembled, place the set (L) on the part (K), tighten with the supplied bolts, as shown in figure 6. Check that the assembly is well placed and tight.
  • Page 12 GlammFire. PAG./12 After complete fixing and the ceiling finishings com- pleted, install the final finishing mirrors. Figure 7— Ceiling finishing mirrors Figure 8—Complete installation of the fireplace to the ceiling...
  • Page 13 GlammFire. PAG./13 Place the lower part of the chimney aligned with the campanula and turn both so that it is similar to figure 10. Figure 9- Bottom of the fireplace Place the rubber base on the bottom of the fireplace to avoid damage to the floor surface.
  • Page 14 GlammFire. PAG./14 Then place the EvoPlus Fire Round burner using the handle supplied to assist in its handling (see burner's instructions manual, chapter: Installation Procedures). Figure 11— Metal handle properly seated Figure 12— Placing the burner in the fireplace without glass...
  • Page 15 GlammFire. PAG./15 Figure 13— Burner placed in the fireplace without glass Figure 14— Burner placed in the fireplace...

  • Page 16: 7-Extension Of Tube (Option)

    PAG./16 7—Extension of tube (option) If the ceiling height of the fireplace installation is larger than 2700mm, GlammFire provides the option of a 500mm extension in order to fit to the desired dimension. This extension has the same diameter of the insert piece with a standard height dimension of 540mm, thus adding 500mm to the piece so that the total length is 1040mm.

  • Page 17: 8-Maintenance

    GlammFire. PAG./17 8—Maintenance The combustion fire line should be cleaned regularly using a damp cloth with bioethanol;  The more persistent marks can be removed using a soft cloth moistened in bioethanol;  Never use chemicals not suitable for cleaning stainless steel;...

  • Page 18: 10-After-Sales Service

    In case of doubt or any anomaly, do not use the fireplace and please contact a specialized technician. 11– Warranty In order to activate your GlammFire 2 year warranty, please register your new GlammFire product at www.GlammFire.com/en/about/warranty complete your warranty card and return it to us, along with a copy of the proof of purchase, at our address within 30 days of purchase.
  • Page 19 Name and Address of the Distributor GlammFire is always concerned with the environment. This is reflected by the projection of their products and their packaging. Focusing on the reduction of energy consumption, raw materials, natural resources and quantity of waste generated, GlammFire follows the policy of the 4R's (Reduce, Reuse, Recycle and Recover).
  • Page 20 Recuperadores Pachinha Lda. Zona Industrial da Lagoa, Lote G1 4950-850 CORTES - MONÇÃO PORTUGAL Tel(+351) 251 654 800 Fax(+351) 251 654 801 info@glammfire.com www.glammfire.com PT12251-A...
