Maintenance Technical Manual

Burner Crea7ion Evo Plus Fire Round

Need help?

Do you have a question about the Crea7ion Evo Plus and is the answer not in the manual?

Questions and answers

Summary of Contents for GlammFire Crea7ion Evo Plus

Page 1 Maintenance Technical Manual Burner Crea7ion Evo Plus Fire Round...
Page 2 GlammFire. PAG./2 Dear Partner, first of all congratulations for being part of the GlammFire family. Like all equipment, the Crea7ion Evo requires preventive maintenance in order to avoid the need for corrective maintenance. This intervention must be annual and the instructions in this manual must be followed step by step.
Page 3 GlammFire. PAG./3 ÍNDICE 1—Limpeza de zona de combustão 2—Limpeza de componentes 2.1—Sensores e termopar 2.2—Tubo do ar 2.3—Limpeza de locais técnicos 2.4—Limpeza de filtro 2.4.2—Filtro interno...
Page 4 GlammFire. PAG./4 Before any kind of intervention on the burner, please read this Instructions Manual carefully. It contains important instructions that should be followed properly in order to ensure good use and durability. All warnings and notices submitted must be respected. Save this manual for future reference.
Page 5 GlammFire. PAG./5 1—Combustion zone cleaning The repeated Bioethanol combustion leaves residues in the burning area which must be properly cleaned. Remove the ring from the combustion zone and clean it in the same way. Using a soft-bristled brush, soak it in Bioetha-...
Page 6 GlammFire. PAG./6 NOTE: During the cleaning of the combustion zone, it is necessary precaution not to touch the resis- tance. If this warning is not taken into account, it is possible that the resistance will break, disabling it.
Page 7 GlammFire. PAG./7 2—Components cleaning All the components of the combustion zone must be cleaned, except the resistance as mentioned before. 2.1—Sensors and thermocouple Using a soft-bristled brush soaked in Bioethanol, proceed to the cleaning of the sensors and thermocouple. THERMOCOUPLE...
Page 8 GlammFire. PAG./8 2.2—Air tube Using a soft-bristled brush soaked in Bioethanol, proceed to the cleaning of the air tube. AIR TUBE...
Page 9 GlammFire. PAG./9 2.3—Cleaning of the technical points There are two technical points in the combustion zone that must be cleaned to guarantee its functionality. Both places are immediately below the two sensors of the combustion zone. Note: After cleaning the combustion zone, replace the ring properly cleaned.
Page 10 GlammFire. PAG./10 2.4—Filters cleaning 2.4.1—Internal filter On the sideline of the safety box, open the side lid by loosening the identified screws. To loosen the identified screws, use a 2.5 mm hex key. Lossen screws...
Page 11 GlammFire. PAG./11 Inside the safety box of the burner, identify the filter tied by a serrated clamp. Cut the clamp carefully. Carefully, pull the filter out of the burner.
Page 12 GlammFire. PAG./12 Put a cloth or absorbent paper in the place, remove the filter by removing the silicone tube at its ends. Use the cloth to absorb the possible ethanol spillage in the tubing or filter.
Page 13 GlammFire. PAG./13...
Page 14 GlammFire. PAG./14 Unscrew the filter and check it for residues. With or without residues, clean it with tap water. When the filter is clean, screw it back and perform the reverse process until the side lid is closed. Note: When cleaning the filter, check the condition of the seal in order to verify that there are no leakages.
