COMPONENT CHECKLIST

AWM 130 Arm
AWM-A13T
Product Quantity
2
AWM 710 Arm
AWM-A71T
Product Quantity
4
750 Post
AWM-P75G
Product Quantity
1
DESK FIXING OPTIONS
Below are the fixing options available for this solution. Fixing installation guides are supplied with the product
or can be accessed through Atdec's website, along with detailed product specifications.
NOTE: Chosen desk fixing must be added to this solution code when ordering.
Post
HEAVY DUTY
F CLAMP
AWM-FH
A
Monitor Arm
(x1)
M4x10mm
A
Monitor Arm
(x1)
A
(x1)
B
Post
Cap
(x1)
B
C
Screw
Security
Screw
(x4)
(x1)
B
VESA Head
(x1)
D
E
Screw
Security
M4x10mm
Screw
(x4)
(x1)
C
D
Screw
Cable Cover
M8
Cap
(x2)
(x8)
GROMMET
CLAMP
AC-GC
AWMS-6-13717 Page 2 of 6
D
4mm
Hex Key
(x1)
C
Channel Clamp
(x1)
F
4mm
Hex Key
(x1)
E
Cable
Cover
(x4)
