User Manual
ATC-3000 TCP/IP to RS232/422/485 Converter

3 Software Setup

ATC-3000 is shipped with default settings shown in the following table:
Property
IP Address
Gateway
Subnet Mask
User Name
Password
COM 1
Link 1

3.1 Configuration by Telnet

You can use Telnet utility to change configuration settings of ATC-3000 by following steps：

3.1.1 Login to the System

Open Ms-DOS command prompt window
Telnet to ATC-3000 using command "Telnet IP address". ( For example：Input Telnet 192.168.0.250 in
Ms-DOS command prompt window).After telnet to ATC-3000, system prompts for a password, the default
password is left it blank. (Figure 3.1)
Note: One can press the default button of ATC-3000 to reset the password to the default value.
After verifying the password, the following terminal screen appears.( Figure 3.2)
192.168.0.250
192.168.0.1
255.255.255.0
admin
admin
9600,None, 8, 1, No flow control, Pack Control disabled, Buffer disabled
Type: TCP Client, Listen port 27010, remote host=0.0.0.0
Figure3. 1 Login to the system
Copyright © 2014 SHENZHEN ATC TECHNOLOGY CO., LTD.
Default Value
