ATC 1000WF Quick Start Manual

Wi-fi to rs-232/422/485

Advertisement

Quick Links

Quick Start Guide
Wi-Fi TO RS-232/422/485
CONVERTER
MODEL ATC-1000WF
(Version 1.0)
1
1
1
.
Check Package Content
■ATC-1000WF unit
■Monopole Antenna (2dBi RP-SMA)
■Software CD
■External power adapter
■Printed version of this ATC-1000WF Quick Start Guide
2
2
. Hardware Installation
■Connect RS-232 DB9 Female Crossing configuration cable
to ATC-1000WF unit on RS-232 side.
■Connecting the Power Adapter to ATC-1000WF power jack.
When the power is properly supplied. The Link LED will
periodic to flash and PWR LED will light in red.
RS-232/422/485 Pinouts
RS-232 Pinout(DB9 Female )
PIN
2
3
5
7
8
RS-422/485 Pinout(SIX Terminal from Left)
PIN
1
2
3
4
5
6
3
3
. LED indication
LINK ---- Indicate WLAN status
ACT ---- It will flash when data transmit between WLAN and
serial port.
PWR ---- Indicate the Power supply
4
4
.Software Installation
1Pcs
1Pcs
I
nsert the software CD and search for such as F:/Tool/
1Pcs
ATC-1000WF to run AXR2W_RS232-to-WiFi _Toolkit_32bit
1Pcs
_v1300.exe.
Note: Be sure you have administrative rights &disable
1Pcs
firewalls in windows XP
5 .
5
Configure the ATC-1000WF
■Before configuring the ATC-1000WF, you should turn off
the power and use a serial cable connect the ATC-1000WF to
your computer's serial port.
■We suggest using Tera-Term to operate.Firstly you should
configure Tera-Term like below.115200bps for baud
rate ,8bits for data-length,NONE for parity bit ,1bit for stop
RS-232
Input/Output
RXD
I
TXD
O
GND
-
RTS
O
CTS
I
RS-422
RS-485
R+
485+
R-
485-
T+
-
T-
-
VIN+
VIN+
VIN-
VIN+
bits .
■ Upon power up, the device will be in data mode. To enter
command mode, you should send ""+++<CR>". The device
will respond with "uart > ".
While in command mode, the device will accept ASCII bytes
as
command.
To
exit
command
"AXCmd2Net".The device will respond with "OK" to data
mode.
The parameters such as the SSID, channel, IP address, serial
port settings, and all other settings can be viewed and
configured in command mode.
6 .
6
Factory Default WLAN &IP Address
UART Parameters
Mode:
RS-232
|
Baud-rate:
Data-length:
8
|
Parity:
Stop-bits:
1
|
Flow :
IP Parameters
Protocol:
TCP Server
Local port::
5000
DHCP Client:
Enabled
Static IP Address:
192.168.2.3
Net Mask:
255.255.255.0
Gateway:
192.168.2.1
DHCP Server:
Enabled
Start IP Address:
192.168.2.4
End IP Address:
192.168.2.10
Net Mask:
255.255.255.0
Gateway:
0.0.0.0
Lease Time:
1440
mode,
send
115200
n (none)
n (none)
1
