2.1.3 SPEED LED

Message
On
Off

2.1.4 PWR LED

Message
On
Off

2.2 Installation Procedures

Step 1: Connect ATC-3000 to power source using 9~24V DC Jack.
Step 2: Connect ATC-3000 to you PC or other device by Ethernet cable.You can use a standard straight-through
Ethernet cable connect it to a hub/switch, or connect it to PC's Ethernet port via a cross-over Ethernet cable.
However, in this case one need to make sure the PC is in the same sub-net as ATC-3000.
Step 3: Connect ATC-3000's serial port to a serial device.
Step 4: Placement options. One can mount ATC-3000 to a wall/panel (Mounting screws included) or Din-Rail
rack.
Table 3. SPEED LED Message
Table4. PWR LED Message
Copyright © 2014 SHENZHEN ATC TECHNOLOGY CO., LTD.
Description
Ethernet is working in 100Mbps
Ethernet is working in 10Mbps
Description
Power on
Power off
