User Manual
ATC-3000 TCP/IP to RS232/422/485 Converter
3.1.5 Serial 0 Settings
Select "5" from "Input choice and enter (1~7 or v s q):" to enter show Serial 0 setting page as following.
( Figure 3.11)
Figure 3. 10 Hostlist 0 setting
In these pages you can configuration the parameters about the serial port and hostlist.

3.2 Configuration Using Web Browser

1. Make sure one PC is located on the same network sub-net as ATC-3000
Open a web browser, then type in the IP address of ATC-3000 to be configured. Default user name is admin and
default password is admin.
2. ATC-3000's network, link mode and COM ports settings can be configured in different web pages.
Click to confirm the parameter which you have changed.
Click "Apply/Restart" to save settings and reboot ATC-3000.
3.
To do so, please follow the steps below.
Copyright © 2014 SHENZHEN ATC TECHNOLOGY CO., LTD.
Figure 3. 11 Serial 0 setting
