Battery Charging - ADJ ELECTRAPIX PAR 7 PAK User Manual

B AT T E R Y C H A R G I N G
The fixture may be charged directly using AC power, or using the optional charging base and power
supply (sold separately). Connect the power supply to a power source on one end, and to the charging
base on the other, then slot the fixture onto the charging base with the charging port side facing
downwards. Refer to the image below.
It is recommended to disconnect the unit from the charger once the battery has reached full
charge. Doing so reduces the risk of overcharging the battery, which can shorten the service life of the
battery.
Please note that the charging components are NOT protected against the intrusion of dust and/
or water, and are intended for use only in a dry indoor environment. Do NOT expose to rain or
moisture. When charging is complete, always seal the charging port with the included plug to
maintain the fixture's IP rating.
FIXTURE
POWER
SUPPLY
CHARGING
BASE
11
