SSV Works X32-PHZ+FK Instruction Manual page 2

FRONT KICK PODS ADD-ON KIT PARTS LIST
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against
defects in material or workmanship. All SSV Works Electronics are covered by a
limited 1 year warranty against defects in material or workmanship. All SSV Works
Speakers are covered by a limited 1 year warranty against defects in material or
workmanship. Labor for replacement of defective components is not covered.
Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- T-30 Torx Driver
- Drill with 1/4" Drill bit
- Scribe or Punch tool
PARTS LIST IMAGES
X3-F65 Enclosures
(1 pair)
Large Bracket x 2
Speaker "Y" Harness
(B-H1463)
2
- Phillips / flat head
screwdriver
- 10 mm wrench
M6 x 1.0 Screws x 6
Small Bracket x 2
RGB "Y"
Splitter(B-H3072)
!
PARTS LIST
1. X3-F65 Enclosures (1 pair)
2. M6 x 1.0 Screws x 6
3. M6 Washers x 6
4. M5 screws and washers 8
M6 Washers x 6
DRIVER SIDE
X3-F65 KICKPOD DRILL TEMPLATE - DRIVER SIDE
Driver Side Template
Front Speaker Harness
(B-H1909)
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
5. Large Bracket x 2
6. Small Bracket x 2
7. Driver Side Template
8. Passenger Side Template
M5 Screws and Washers
x 8
X3-F65 KICKPOD DRILL TEMPLATE - PASSENGER SIDE
Passenger Side Template
RGB Speaker Harness
(B-H2935)
SPEAKER
WIRE
PASSENGER SIDE
