Omcan IC-CN-0050 Instruction Manual page 9

Model IC-CN-0050
Item No. Description
AL507 Cover for 47467
AL508 Magnet for 47467
AL509 Top Part for 47467
AL510 Screw ST4x10 for 47467
AL511 Front Panel for 47467
AL512 On/Off Switch for 47467
AL513 Pressing Ring for 47467
AL514 Guiding Ring for 47467
AL515 Rotary Component for 47467
AL516 Hopper for 47467
AL517 Inner Hexagonal Screw M8x20 for 47467
AL518 Nut M8 for 47467
AL519 Spacer 8 for 47467
AL520 Blade for 47467
AL521 Screw M5x12 for 47467
AL522 Spacer 5 for 47467
AL523 Blade Adjuster for 47467
AL524 Dowel for 47467
AL525 Screw Arbor for 47467
47467
Position Item No. Description
1 AL526 Spacer 8 for 47467
2 AL527 Blade Support for 47467
3 AL528 Outer Hexagon Bolt M5x14 for 47467
4 AL529 Outer Hexagon Bolt M5x32 for 47467
5 AL530 Shaved Ice Guide Bushing for 47467
6 AL531 Adjuster Knob for 47467
7 AL532 Support Rods for 47467
8 AL533 Hopper Base for 47467
9 AL534 Water Pipe 13x10-300 for 47467
10 AL535 Motor Support for 47467
11 AL536 Front Shell for 47467
12 AL537 Base for 47467
13 AL538 Water Pipe 17x14-800 for 47467
14 AL539 Grid Cover for 47467
15 AL540 Feet for 47467
16 AL541 Screw BT4x12 for 47467
17 AL542 Belt for 47467
18 AL543 Big Drive Pulley for 47467
19 AL544 Holding Screw M5x15 for 47467
Parts Breakdown
Position Item No.
20 AL545
21 AL546
22 AL547
23 AL548
24 AL549
25 AL550
26 AL551
27 AL552
28 AL553
29 AL554
30 AL555
31 AL556
32 AL557
33 AL558
34 AL559
35 AL560
36 AL561
37 AL562
38 AL563
9
Description Position
Small Drive Pulley for 47467 39
Motor for 47467 40
Outer Hexagon Bolt M10x25 for 47467 41
Spacer 10 for 47467 42
Back and Side Shell for 47467 43
Cable Clip for 47467 44
Power Cord for 47467 45
Fuse Cover for 47467 46
Handles for 47467 47
Capacity for 47467 48
Wiring Harness for 47467 49
Chief Axis for 47467 50
Spring for 47467 51
Bearing 35x14x11 for 47467 52
Microswitch for 47467 53
PE Bag for 47467 54
Left Foam for 47467 55
Right Foam for 47467 56
Carton for 47467 57
