- Page 1 Ice Shaver Model IC-CN-0050 Item 47467 Instruction Manual Revised - 11/02/2022 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model IC-CN-0050 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 5 Technical Specifications -------------------------------------------------------------------------- 6 Operation ----------------------------------------------------------------------------------------- 6 - 7 Parts Breakdown ------------------------------------------------------------------------------- 8 - 9 Electrical Schematics ---------------------------------------------------------------------------- 10 Warranty Registration... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR PARTS AND LABOUR BENCH WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.
-
Page 6: Technical Specifications
Technical Specifications Model IC-CN-0050 Hopper Capacity 16.9 lbs. / 1.5 kgs. Ice Shaving Capacity 264.6 lbs. / 120 kgs. per hour Electrical 110V / 60Hz / 1 Power 0.33 HP / 250 W Rotate Speed 320 RPM Rotary Component Aluminum Alloy 1.4”... -
Page 7: Operation
Operation Rotate the knob counterclockwise to the end before switch on the machine. Rotate the knob clockwise slowly if smaller size ice is needed during operation. NOTE: Do not turn the knob counterclockwise during standard operation. Doing so may cause the already shaved ice to block the blade. -
Page 8: Parts Breakdown
Parts Breakdown Model IC-CN-0050 47467... - Page 9 Parts Breakdown Model IC-CN-0050 47467 Item No. Description Position Item No. Description Position Item No. Description Position AL507 Cover for 47467 AL526 Spacer 8 for 47467 AL545 Small Drive Pulley for 47467 AL508 Magnet for 47467 AL527 Blade Support for 47467...
-
Page 10: Electrical Schematics
Electrical Schematics Model IC-CN-0050 47467... -
Page 11: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 12 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
