8. Attachment and operation
Attention!
Always make sure the product is fully assembled be-
fore commissioning!
8.1 Assembling the trim, chop and mitre saw
(fig. 1, 2, 4, 5, 21)
• In order to adjust the rotary table (14), fold the lock-
ing handle (11) upwards and pull up the latched posi-
tion lever (34) with your index finger.
• Turn the rotary table (14) and pointer (12) to the de-
sired angle measurement of the scale (13). To fix the
setting, fold the locking handle (11) downwards.
• Pressing the machine head (4) lightly downwards
and removing the locking bolt (23) from the motor
bracket at the same time disengages the saw from
the lowest position.
• Swing the machine head (4) up.
• It is possible to secure the clamping devices (7) to
the left or right on the fixed saw table (15). Insert the
clamping devices (7) in the holes on the rear side
of the stop rail (16) and secure it with the star grip
screws (7a).
• You can press the quick locking button (7b) to adjust
the clamping device's pressure plate (7) easily to the
workpiece height.
• For 0°- 45° mitre cuts, the clamping device (7) must
only be mounted on the right side (see fig. 11-12).
• It is possible to tilt the machine head (4) a max. 45°
to the left by loosening the set screw (22).
• Workpiece supports (8) must always be secured and
used during work. Set the desired table size by loosening
the set screw (9). Then tighten the set screw (9) again.
8.2 Precision adjustment of the stop for crosscut
90° (fig. 1, 2, 5, 6)
No stop angle included.
• Lower the machine head (4) and secure it using the
locking bolt (23).
• Loosen the set screw (22).
• Position the angle stop (A) between the saw blade
(6) and the rotary table (14).
• Loosen the lock nut (26a).
• Adjust the adjusting screw (26) until the angle be-
tween the saw blade (6) and rotary table (14) is 90°.
• Re-tighten the lock nut (26a).
• Subsequently check the position of the angle indi-
cator. If necessary loosen the pointer (19) using a
Philips screwdriver, set to position 0° on the angle
scale (18) and re-tighten the retaining screw.
34 | GB www.scheppach.com
8.3 Crosscut 90° and turntable 0° (fig. 1, 2, 7)
In the case of cutting widths up to approx. 100 mm it
is possible to fix the traction function of the saw with
the set screw (20) in the rear position. In this position
the machine can be operated in cross cutting mode. If
the cutting width is over 100 mm then it is necessary to
ensure that the set screw (20) is loose and the machine
head (4) can move.
Attention!
For 90° crosscuts, the moveable stop rail (16a) must be
fixed in the inner position.
• Open the set screw (16b) for the moveable stop rail
(16a) and push the moveable stop rail (16a) inwards.
• The moveable stop rail (16a) must be locked in a po-
sition far enough from the inner position that the dis-
tance between the stop rail (16a) and the saw blade
(6) is no more than 8 mm.
• Before making the cut, check that the stop rail (16a)
and the saw blade (6) cannot collide.
• Re-tighten the set screw (16b).
• Move the machine head (4) to its upper position.
• Use the handle (1) to push back the machine head
(4) and fix it in this position if required (dependent on
the cutting width).
• Place the piece of wood to be cut at the stop rail (16)
and on the turntable (14).
• Lock the material with the clamping devices (7) on
the fixed saw table (15) to prevent the material from
moving during the cutting operation.
• Release the lock switch (3) and press the ON/OFF
switch to start the motor.
• With the drag guide (21) fixed in place:
use the handle (1) to move the machine head (4) stead-
ily and with light pressure downwards until the saw
blade (6) has completely cut through the work piece.
• With the drag guide (21) not fixed in place:
pull the machine head (4) all the way to the front.
Lower the handle (1) to the very bottom by apply-
ing steady and light downward pressure. Now push
the machine head (4) slowly and steadily to the very
back until the saw blade (6) has completely cut
through the work piece.
• When the cutting operation is completed, move the
machine head back to its upper (home) position and
release the ON/OFF button (2).
Attention!
The machine executes an upward stroke automati-
cally due to the return spring, i.e. do not release the
handle (1) after completing the cut; instead allow the
machine head to move upwards slowly whilst apply-
ing light counter pressure.
8.4 Crosscut 90° and turntable 0° - 45°
(fig. 1, 7, 8)
The trim, chop and mitre saw can be used for angled
cuts of 0°-45° to the left and right.
Important!
For 90° crosscuts, the moveable stop rail (16a) must be
fixed in the inner position.
• Open the set screw (16b) for the moveable stop rail
(16a) and push the moveable stop rail (16a) inwards.
• The moveable stop rail (16a) must be fixed far
enough in front of the innermost position that the dis-
tance between the stop rail (16a) and the saw blade
(6) amounts to a minimum of 8 mm.
• Before making the cut, check that the stop rail (16a)
and the saw blade (6) cannot collide.
• Secure the set screw (16b) again.
• Loosen the locking handle (11) if tightened, pull up
the latched position lever (34) with your index finger
and use the locking handle (11) to set the rotary table
(14) to the desired angle.
• The pointer (12) on the rotary table must match the
desired angle on the scale (13) on the fixed saw ta-
ble (15).
• Re-tighten the locking handle (11) to secure the ro-
tary table (14).
• Cut as described under section 8.3.
8.5 Precision adjustment of the stop for mitre cut
45° (fig. 1, 2, 5, 9, 10)
No stop angle included.
• Lower the machine head (4) and secure it using the
locking bolt (23).
• Fix the rotary table (14) in the 0° position.
Attention!
For mitre cuts (inclined saw head), the left side of
the moveable stop rails (16a) must be fixed in the
outer position.
• Open the set screw (16b) for the moveable stop rail
(16a) and push the moveable stop rail (16a) out-
wards.
• The moveable stop rail (16a) must be fixed far
enough in front of the innermost position that the dis-
tance between the stop rail (16a) and the saw blade
(6) amounts to a maximum of 8 mm.
• The right side of the moveable stop rails (16a) must
be in the inner position.
• Before making a cut, check that the stop rail (16a)
and the saw blade (6) cannot collide.
• Loosen the set screw (22) and use the handle (1) to
angle the machine head (4) 45° to the left.
www.scheppach.com
• 45° - position angle stop (B) between the saw blade
(6) and rotary table (14).
• Loosen the lock nut (27a) and adjust the adjustment
screw (27) until the angle between the saw blade (6)
and the rotary table (14) is precisely 45°.
• Re-tighten the lock nut (27a).
• Subsequently check the position of the angle indi-
cator. If necessary, loosen the pointer (19) using a
Philips screwdriver, set to position 45° on the angle
scale (18) and re-tighten the retaining screw.
8.6 Mitre cut 0°- 45° and turntable 0° (fig. 1, 2, 11)
The trim, chop and mitre saw can be used for mitre cuts
of 0°- 45° to the left of the work surface.
Attention!
For mitre cuts (inclined saw head), the left side of the
moveable stop rails (16a) must be fixed in the outer po-
sition.
• Open the set screw (16b) for the moveable stop rail
(16a) and push the moveable stop rail (16a) outwards.
• The moveable stop rail (16a) must be fixed far
enough in front of the innermost position that the dis-
tance between the stop rail (16a) and the saw blade
(6) amounts to a minimum of 8 mm.
• The right side of the moveable stop rails (16a) must
be in the inner position.
• Before making a cut, check that the stop rail (16a)
and the saw blade (6) cannot collide.
• Secure the set screw (16b) again.
• Move the machine head (4) to the top position.
• Fix the rotary table (14) in the 0° position.
• Loosen the set screw (22) and use the handle (1) to
angle the machine head (4) to the left, until the point-
er (19) indicates the desired angle measurement on
the scale (18).
• Re-tighten the set screw (22).
• Cut as described in section 8.3.
8.7 Mitre cut 0°- 45° and turntable 0°- 45°
(fig. 2, 4, 12)
The trim, chop and mitre saw can be used for mitre cuts
of 0°- 45° to the left of the work surface and of 0°- 45° to
the stop rail (double mitre cut).
Attention!
For mitre cuts (inclined saw head), the left side of the
moveable stop rails (16a) must be fixed in the outer po-
sition.
• Open the set screw (16b) for the moveable stop rail
(16a) and push the moveable stop rail (16a) out-
wards.
GB | 35
