Ultra UV2
Tank Replacement
Installation Manual
8175 W. Buckeye Rd.,
Phoenix, AZ 85043
Phone: (480) 893-7607
www.1Paramount.com
USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS
Contents
Safety Instructions..................1
Installation.............................2
Electrical Wiring......................7
Replacement Parts.................11
005-422-3100-00
005-422-3000-00
Pool, Spa & Pond
Water Sanitizer 4BJ1
Paramount
004-027-8707-00 RevG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra UV2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paramount Fitness Ultra UV2

Summary of Contents for Paramount Fitness Ultra UV2

  • Page 1 004-027-8707-00 RevG Ultra UV2 Tank Replacement Installation Manual Contents Safety Instructions....1 Installation......2 Electrical Wiring......7 Replacement Parts....11 005-422-3100-00 005-422-3000-00 Pool, Spa & Pond Water Sanitizer 4BJ1 Paramount 8175 W. Buckeye Rd., Phoenix, AZ 85043 Phone: (480) 893-7607 www.1Paramount.com USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...

  • Page 2: Safety Instructions

    Important Safety Instructions READ AND FOLLOW ALL INSTRUCTIONS PLEASE REVIEW THE INSTALLATION GUIDE IN ITS ENTIRETY AND HEED ALL SAFETY INFORMATION. Failure to follow these instructions and warnings can result in DEATH OR SERIOUS INJURY. This Owner’s Manual contains specific precautions and symbols to identify safety related infor- mation as described below.

  • Page 3: Installation

    - 24 hour cure time is required before pressure (50psi max) can be applied to the Ultra UV2 unit. DANGER - Turn off the power supply to the old Ultra UV2 unit. Turn off power to the pool pump. Disconnect the input power to the installed Ultra UV2: •...
  • Page 4 Use ONLY ABS to PVC multipurpose glue & appropriate primer, install the supplied blanking plugs & unions to new replacement tank. Bonding Lug • Be sure to match the placement of the fittings on the old tank. Note the orientation of the incoming •...
  • Page 5 - Before removing lamps you must wear protective rubber gloves and safety eye wear. Do not handle a hot lamp or serious burns will occur. Identify Your Ultra UV2 Unit and Follow Instructions Accordingly Ultra UV2 Configuration 1 (See Below)
  • Page 6 Disconnect all lamps by pressing the Carefully lift the old lamp assembly from release tabs on connectors and gently the quartz tube. Set aside the lamp pulling apart. assembly in a safe area to avoid breaking. Metal Disk Remove metal disk from the old quartz Remove the black plastic nut from the tube and place it gently into the new new tank and install the aluminum nut...
  • Page 7 Ultra UV2 Configuration 2 Remove Retaining Clip The lamp array is held in place by an Squeeze the ends of the retaining clip to aluminum cup. remove. Disconnect all lamps by pressing the Carefully lift the lamp assembly from the...

  • Page 8: Electrical Wiring

    Installing Ballast(s) Into New Tank Using supplied connector tool, disconnect Remove ballast(s) from the old tank and the green, white and black wires from the install onto the integrated brackets on the ballast by inserting the tool in the slot next new tank with the wire input side facing to the wire and pull gently until the wire is the pressure switch.
  • Page 9 Single Ballast Wiring Connect the color wires to the corresponding color inputs in the ballast. Two Ballasts Wiring Remove the pre-wired single white wire Install the supplied double white wire (E) (B) from the left side of the terminal block. to the terminal block.
  • Page 10 Remove the short black wire(s) (F) from Install the supplied dual black wire (D) to the top terminal of pressure switch. the pressure switch, then to both black connectors of the ballasts. Using one of the green ground wires (D), Connect all color wires to corresponding connect it to the right ground post.
  • Page 11 Connecting Ultra UV2 Unit to Power Source For Hard-Wired Units Install conduit into seal-tight connector. Lift the grommet from the mounting plate Replace conduit if it is too short. Replace and feed the two power wires & and wires if any are too short. A 10' bundle of ground wire.

  • Page 12: Replacement Parts

    For 120/230V Hard-Wired Units: For 120V Corded Units: Install the bonnet. Install the bonnet. Turn on the breaker for the Ultra UV2 unit. Connect the corded plug into previously Power on the pump and ensure that the used GFCI receptacle.
  • Page 13 USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
  • Page 14 THIS PAGE IS INTENTIONALLY LEFT BLANK USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
  • Page 15 THIS PAGE IS INTENTIONALLY LEFT BLANK USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
  • Page 16 For further information or consumer technical support, visit our website at www.1Paramount.com Hayward is a registered trademark of Hayward Industries, Inc. © 2024 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
