Paramount Fitness MDX2 retro Installation Manual

Anti-entrapment debris drain
Hide thumbs Also See for MDX2 retro:

Advertisement

Safety compliant according to the Virginia
Graeme Baker Pool and Spa Safety Act
ASME A112.19.8 - 2007 LISTED
U.S. Patent No.: 6,810,537, 7,089,607, 7,178,179
Notice to Installers:
Read and follow these instructions. Give these instructions to
the facility owner to keep for future reference. Follow all codes
and regulations that apply to the design, installation and use
of suction outlet fittings. Only for use in pools with an existing
MDX or MDX Sump.
WARNING: MDX² and SDX must be installed in accordance
with Paramount's written instruction manual, and in conformi-
ty with applicable Federal, State, Local and Swimming pool
industry building and safety codes.
MDX0805
004-027-8792-00
295 East Corporate Place • Suite 100 • Chandler, AZ 85225
T oll Free: 1.800 . 621.5886 • Phone: 480.893.7607 • Fax: 480.753.3397
Paramount@1Paramount.com • www.1Paramount.com
MDX² INSTALLATION MANUAL
MADE IN USA
REV040109
ANTI-ENTRAPM ENT DEBRIS DRAIN
ANTI-ENTRAPM ENT DEBRIS DRAIN
(RETROFIT FIBERGLASS, VINYL &
CONCRETE POOLS WITH MDX)
SUBMERGED SUCTION OUTLET
FOR MUL TIPLE DRAIN USE
FOR USE ON FLOOR
AS A REPLACEMENT FOR
Only for Pools
with an existing
MDX sump
® ®
MDX DRAINS ONL Y

Advertisement

loading
Need help?

Need help?

Do you have a question about the MDX2 retro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Paramount Fitness MDX2 retro

  • Page 1 Only for Pools with an existing MDX sump ® ® ANTI-ENTRAPM ENT DEBRIS DRAIN ANTI-ENTRAPM ENT DEBRIS DRAIN MDX² INSTALLATION MANUAL (RETROFIT FIBERGLASS, VINYL & CONCRETE POOLS WITH MDX) SUBMERGED SUCTION OUTLET FOR MUL TIPLE DRAIN USE FOR USE ON FLOOR AS A REPLACEMENT FOR MADE IN USA Safety compliant according to the Virginia...
  • Page 2 IMPORTANT NOTICES: PLEASE READ WARNING KNOWN DROWNING HAZARD. DO NOT GO NEAR THE SUCTION FITTINGS OR DRAINS OF YOUR POOL OR SPA. YOUR HAIR OR BODY MAY BECOME TRAPPED CAUSING PERMANENT INJURY OR DROWNING. DO NOT ENTER THE POOL OR SPA IF SUCTION FITTINGS OR DRAIN COVERS ARE LOOSE, BROKEN, OR MISSING.
  • Page 3 MDX² RETRO INSTALLATION MANUAL NOTICE — Maximum Pump Size: MDX² Retro is rated for a maximum of 90 GPM (340 LPM). While system flow rate will vary with pump size and the Total Head Loss for a given system, virtually any modern pump is capable of exceeding this limit, therefore it is the responsibility of the system designer to make sure it is not possible to exceed 90 GPM (340 LPM).
  • Page 4 005-252-2085-XX Cover (XX=Color Code) Screw: No. 10 ” Vinyl Security Head X3/4 Screw: No. 8 Security Head X3/8” Concrete anchors screw 10 x 1 1/4” security head 005-202-2213-00 Screw Pack MDX2 Retro (includes 3,4,6,8,9,10,11) * Not part of MDX² Retro...
  • Page 5 MDX² - CONCRETE DRAIN ASSEMBLY Concrete Drain Assembly (with leveling ring): After draining the pool: Position the Retro Lower Support (001-250-2064-00) over the existing sump as Fig. 1 shown in figure 1 and attach with the screws (6) and anchor clips (3) provided by Paramount. (Fig.
  • Page 6 004-202-2221-XX MDX² RETRO FOR CONCRETE WITH LEVELING RING Replace within 05 installed years Item Part Number Description 005-202-2018-00 Sump MDX Concrete - 2½" (must be present in the pool) Leveling Ring Clip Anchor MDX 2 Fiber Retro 005-252-2070-00 005-202-2209-00 Lower Support Concrete Anchors Screw No.
  • Page 7 MDX² - VINYL DRAIN ASSEMBLY Vinyl Drain Assembly: Install lower support (#4) onto sump (#1) with 4 (four) security screws (#2 and #3) with screw driver security T25. Install upper support (#5) onto lower support (#4) and secure with 8 (eight) security screws (#6). Install the cover (#7) onto the upper support (#5) and secure with 6 (six) phillips screws (#8) and 2 (two) phillips screws (#9).
  • Page 8 MDX² - FIBERGLASS DRAIN ASSEMBLY Fiberglass Drain Assembly: Install lower support (#5) onto sump (#1) with 6 (six) security screws (#6 and #4) and two anchor clips (#3) (#005-252-2070-00) with screw driver security T25. Install upper support (#7) onto lower support (#5) and secure with 8 (eight) security screws (#8). Install the cover (#9) onto the upper support (#7) and secure with 6 (six) phillips screws (#10) and 2 (two) phillips screws (#11).
  • Page 9 MDX² VINYL WINTERIZATION WITH CANISTER WITHOUT CANISTER If vacuum relief suction outlets are located below freeze If vacuum relief suction outlets are located below freeze line skip steps 1 and 2. line skip steps 1 and 2. Remove grate from second suction and install a Remove grate from second suction and install a 13-¾...
  • Page 10 Notes...
  • Page 11 Notes...
