Paramount Fitness Ultra UV2 Replacement Manual

Lamp assembly installation & lamp replacement
Hide thumbs Also See for Ultra UV2:
1
2
3
4

Advertisement

Table of Contents

WARNING
• Follow all applicable electrical codes.
• Turn off power at main source before making any electrical connections or servicing the unit.
• To reduce the risk of electric shock, injury or death disconnect unit from power supply
• Follow the instructions or risk of serious injury or death could occur!
UV EXPOSURE & PROTECTION:
UV-A and UV-B radiation can have adverse short and long term effects on the eyes and skin. Never
look directly at a UV lamp that is connected to a power source. Avoid UV skin exposure at all times.
Indicates a hazardous situation
DANGER
which, if not avoided, will result
in death or serious injury.
Indicates a hazardous situation
CAUTION
which, if not avoided, could result
in minor or moderate injury.
295 East Corporate Place • Suite 100 • Chandler, AZ 85225
Toll Free: 1.800.621.5886 • Phone: 480.893.7607 • Fax: 480.753.3397
Paramount@1Paramount.com • www.1Paramount.com
004-027-8833-00
Pool, Spa & Pond
Water Sanitizer 4BJ1
REV 00
Publish 112116
LAMP ASSEMBLY
INSTALLATION & LAMP
REPLACEMENT MANUAL
The UV lamps have a useful life of
approximately 13,000 hours and should
be replaced at that time. Even though the
lamp(s) may be glowing after 13,000 hours of
operation they have reached the end of their
useful life.
IMPORTANT SAFETY INSTRUCTIONS: READ
COMPLETELY BEFORE PROCEEDING.
When using this electrical equipment, basic safety precautions
should always be followed, including the following:
WARNING
NOTICE
EPA Registered
#084221-AZ-001
ECN_1122
Indicates a hazardous situation
which, if not avoided, could
result in death or serious injury.
Is used to address practices
not related to physical injury.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra UV2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paramount Fitness Ultra UV2

Summary of Contents for Paramount Fitness Ultra UV2

  • Page 1 LAMP ASSEMBLY INSTALLATION & LAMP REPLACEMENT MANUAL The UV lamps have a useful life of approximately 13,000 hours and should be replaced at that time. Even though the lamp(s) may be glowing after 13,000 hours of operation they have reached the end of their useful life.
  • Page 2 Fig. 2 Fig. 1 Fig. 3 1. Turn off all power to the ULTRA UV2 unit and all other pool equipment. Unplug the unit from its power receptacle or turn OFF the circuit breaker that is the ULTRA UV2’s power source. Before proceeding to step 2 allow at least 15 minutes for the lamp(s) in the unit to cool.
  • Page 3 5. Carefully remove new lamp assembly from box. Insert Fig. 7 lamp(s) into lamp holder. lamp(s) must be aligned and seated securely in the lamp holder. Roll the black o-ring(s) up onto the ceramic end of lamp from position A to B, Fig. 8. Gently insert lamps into the lower lamp retainer Fig.
  • Page 4 A to B, Fig. 8. Gently insert lamps into the lower lamp retainer Fig. 9 and lower lamp assembly into unit. 3. Reverse order to reconnect the UV lamp(s) into Ultra UV2 unit. 4. Discard lamp(s) appropriately. Visit www.lamprecycle.org for instructions on disposal.
