004-027-8746-00 R04
ECN_2418 PUB062823
SDX2 Retro
High Flow Safety Drain for Concrete
Installation Manual
Contents
Safety Instructions..................1
Introduction............................3
Installation.............................4
Bulb Replacement.................14
Troubleshooting....................16
Replacement Parts.................17
Warranty................................19
VGB Compliant ANSI/APSP/ICC-16 2017 LISTED
Paramount
8175 W. Buckeye Rd.,
Phoenix, AZ 85043
Phone: (480) 893-7607
www.1Paramount.com
USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Paramount Fitness SDX2 Retro
Summary of Contents for Paramount Fitness SDX2 Retro
- Page 1 004-027-8746-00 R04 ECN_2418 PUB062823 SDX2 Retro High Flow Safety Drain for Concrete Installation Manual Contents Safety Instructions....1 Introduction......3 Installation......4 Bulb Replacement....14 Troubleshooting....16 Replacement Parts....17 Warranty........19 VGB Compliant ANSI/APSP/ICC-16 2017 LISTED Paramount 8175 W. Buckeye Rd., Phoenix, AZ 85043 Phone: (480) 893-7607 www.1Paramount.com...
- Page 2 Important Safety Instructions READ AND FOLLOW ALL INSTRUCTIONS This Owner’s Manual contains specific precautions and symbols to identify safety related infor- mation as described below. Please read them carefully and follow these precautions as indicated! DANGER - Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
- Page 3 DANGER - DEATH or SERIOUS INJURY will result from pool or spa drain covers or grates that are improperly installed, missing, clogged, or broken. • Inspect pool and spa before each use to ensure that drain covers and grates are prop- erly in place and secured.
- Page 4 • A clogged drain can negatively affect the safety of the drain. • It is advisable to have a qualified pool or spa professional perform this inspection and debris removal from the pool an spa drain covers. • When servicing the drain cover, the pump connected to the suction must be turned off. •...
- Page 5 For more information about the Virginia Graeme Baker Pool and Spa Safety Act, contact the Consumer Product Safety Commission at (301) 504-7908 or visit www.cpsc.gov. WARNING - Always turn off all power to the pool pump before installing the cover or work- ing on any suction outlet.
- Page 6 General Information The SDX2 high flow drain system is a dual-drain system designed and tested to safely deliver water to modern high flow pumps. Each Drain Addresses All Entrapment Hazards Hair Entrapment Avoidance. At the heart of the patented design is a cover that acts much like sixty self-regulating drains.
- Page 7 SDX2 is a circulation drain, not intended to remove debris. For this reason it is suggested SDX2 be installed on walls whenever possible. SDX2 is a high fl ow safety drain system submerged suction outlet suitable for single or multiple drain use on the wall and floor. This is to keep debris and sand from collecting on and around the low velocity SDX2 cover.
- Page 8 The flow rating for pools with multiple, blockable SOFAs piped together in one body of water without isolation valves shall be determined by combining the flow rating of all SOFAs, minus the flow rating of one. If the flow ratings of all SOFAs are not equal, subtract the flow rating of the SOFA with the highest flow rating. The flow rating for existing pools with a single, blockable SOFA is the flow rating of the SOFA, when also installed in conjunction with an additional device or system designed to prevent suction entrapment, where the additional device or systems is of a type listed in section 9.4 of ANSI/APSP/ICC-16-2017.
- Page 9 SDX2 RETRO is an underwater suction drain cover system intended to replace any drain cover up to 10 inches in diameter. SDX2 is approved for single or multiple drain use. When retrofitting a SDX2 to an existing instal- lation with a single suction outlet that is not listed and approved for use as a single suction outlet one of the following must be added in accordance with ANSI/APSP-7.
- Page 10 Fig. 2 Determine from the following choices which provided screws, fasteners, and spacers to use to attach the drain cover support plate to the pool or spa surface. CAUTION - Do not install screws until reading sec- tion regarding installing support plate on pages 10 & 3a.
- Page 11 CAUTION - FAILURE TO USE THE CORRECT SPACERS MAY CAUSE THE POOL COVER SUPPORT PLATE TO BE PULLED FROM THE POOL OR SPA SURFACE. IF the spacers provided do not properly fill the gap because of pool interior surface level in relation to the sump or embedded ring stop. Do not use the threaded inserts go to method described in step 3E to complete the installation.
- Page 12 Completely hand tighten screws to 18 in-lbs. Do not use power tools. Fig. 8 If the SDX2 Retro is on a curved wall such as a spa, or the wall/floor of the pool is uneven, then the gap between the back plate of the SDX2 and the pool finish must be filled.
- Page 13 Fig. 9 Attached without spacers Attached with both spacers and and threaded inserts threaded inserts Fig. 10 Trim tabs flush to fit in support plate Fig. 11 USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
- Page 14 005-252-2099-XX SDX2 Retro Cover with Screws 005-252-2067-00 SDX2 Retro Support SDX2 Retro Screw Pack for Concrete 005-252-0886-00 Includes: Screws, Trim Pack, TORX Wrench T-25 Security **Replace cover within 5 installed years. Please indicate your color choice by placing the appropriate color code in place of the “XX" at the end of the part number.
- Page 15 USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
- Page 16 For further information or consumer technical support, visit our website at www.1Paramount.com Hayward is a registered trademark of Hayward Industries, Inc. © 2023 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
