Paramount Fitness Ultra UV2 Owner's Manual

Ultimate uv water sanitizer

Advertisement

Ultra UV2
Ultimate UV Water Sanitizer
Owner's Manual
Plug In 120V Models
1 Lamp
004-422-2021-00
2 Lamps
004-422-2022-00
3 Lamps
004-422-2023-00
Pool, Spa & Pond
Water Sanitizer 4BJ1
8175 W. Buckeye Rd.,
Phone: 1-800-621-5886
www.1Paramount.com
USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS
Contents
Safety Instructions..................1
Introduction............................3
Installation.............................4
System Start-Up....................10
Maintenance.........................12
FAQs.....................................16
Troubleshooting....................17
Replacement Parts................21
Hard Wired 120/230V Models
Paramount
Phoenix, AZ 85043
004-027-9000-00 REV06
ECN_2365 PUB032423
004-422-2025-00
004-422-2026-00
004-422-2027-00
EPA Est. No.
101936-SGP-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra UV2 and is the answer not in the manual?

Questions and answers

Van Miller
May 31, 2025

Water leaks out from the circular light at the middle of the unit. Could this be do to a faulty o ring at the top of the inner glass tube?

1 comments:
Mr. Anderson
May 31, 2025

Yes, a faulty O-ring at the top of the inner quartz tube could cause water to leak, which may lead to water entering the electrical enclosure and tripping the GFCI on the Ultra UV2 unit.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Paramount Fitness Ultra UV2

  • Page 1: Table Of Contents

    004-027-9000-00 REV06 ECN_2365 PUB032423 Ultra UV2 Ultimate UV Water Sanitizer Owner's Manual Contents Safety Instructions....1 Introduction......3 Installation......4 System Start-Up....10 Maintenance......12 FAQs........16 Troubleshooting....17 Replacement Parts....21 Plug In 120V Models Hard Wired 120/230V Models 1 Lamp 004-422-2021-00 004-422-2025-00 2 Lamps 004-422-2022-00 004-422-2026-00...
  • Page 2: Safety Instructions

    Important Safety Instructions READ AND FOLLOW ALL INSTRUCTIONS This Owner’s Manual contains specific precautions and symbols to identify safety related infor- mation as described below. Please read them carefully and follow these precautions as indicated! DANGER - Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 3 Table of Contents Important Safety Instructions....................1 Introduction..........................3 General Product Information....................3 Ultra UV System Sizing.....................3 Installation..........................4 Locating The Ultra UV Unit....................4 Mounting the UV Unit on a Solid Base.................5 Installing Inlet/Outlet Unions....................5 Plumbing The Ultra UV Unit....................5 Typical Plumbing With and Without Bypass..............6 Parallel Plumbing With and Without Bypass..............7 Mutiple Port Plumbing for 3 Lamp Units With and Without Bypass.........7 Electrical Wiring.........................8...
  • Page 4: Introduction

    - Do not use this unit for potable (drinking) water sanitation. Ultra UV2 System Sizing In order to ensure that your Ultra UV2 unit functions with the proper water exposure time to achieve the desired water sanitation, it is important to provide the proper water flow rate through the Ultra UV2 unit.
  • Page 5: Installation

    Header size should be 2½" or 3" and split to two 2" pipe headers at the inlet and outlet connections. Installation NOTICE - The first step in starting your installation is to inspect the Ultra UV2 unit for damage, paying close attention to the quartz tube. Locating the Ultra UV2 Unit Your unit can be installed indoors or outdoors.
  • Page 6: Installing Inlet/Outlet Unions

    A minimum of 24 hours is recommended. Maximum test pressure for the Ultra UV2 is 50 PSI / 3.45 BAR as noted on the silver label on the unit. If local codes require the pressure test to be higher than the max operating pressure on the silver label, use the...
  • Page 7 (if the unit is plumbed with a bypass) to ensure that the Ultra UV2 is at or below the max operating pressure. A. Plumbing the Ultra UV2 Unit with Optional Bypass Valve Installing a bypass is not recommended and should only be considered: To allow for removal of the UV unit for winterization, servicing, repairs, or replacement, while still allowing water to flow through the system.
  • Page 8: Parallel Plumbing With And Without Bypass

    Parallel Plumbing With and Without Bypass Plumbing Ultra UV2 units in parallel for large bodies of water with high flow rates. B. Optional Flow Switch Filter To Heater or Pool Pump A. Optional bypass View fully closed. This pipe does not exist...
  • Page 9: Electrical Wiring

    (GFCI). The electrical power rating for your Ultra UV2 unit is shown on the silver label located on the outside of the unit (shown in the image on page 4). Make sure the supplied power meets the electrical re- quirements.
  • Page 10: Hard Wired 120/230V 50/60Hz Ultra Uv Units

    Hard Wired 120/230V 50/60Hz Ultra UV2 Units Fig. 1 NOTICE - Have this work done by a licensed Bonding Lug electrical technician. Install the conduit into the seal-tight connector. Lift the grommet from the mounting plate and feed the black, white, and green wires (Fig. 2).
  • Page 11: System Start-Up

    The Ultra UV2 unit is equipped with pressure a switch that does not allow the UV lamp(s) inside the unit to light unless there is at least 2 PSI (0.137 BAR) inside the Ultra UV2 reactor chamber. This will ensure that the lamp(s) will illuminate when the Ultra UV2 unit has water flowing through the reactor.
  • Page 12: Normal Operation

    Configuration for Ultra UV2 units installed with bypass. Bypass operation is used for winterization or servicing the Ultra UV2 unit. The bypass valve #1 should be fully open and the inlet valve #2 and the outlet valve #3 should be completely closed.
  • Page 13: Maintenance

    Winterization of Your Ultra UV2 Unit If you are in a sub freezing climate, you must winter- ize the Ultra UV2 using either option #1 or #2. Failure to do so will cause damage to the unit, which is not covered under the warranty.
  • Page 14: Quartz Tube Maintenance

    - The quartz tube requires cleaning every 6 months to ensure optimum performance. Turn off all power to the Ultra UV2 unit and all other pool equipment. Unplug the unit from its power recep- tacle or turn OFF the circuit breaker that is the Ultra UV2’s power source.
  • Page 15 ½ turn. Fig. 17 12. Turn power on to the Ultra UV2 unit. Turn pump on to check for leaks. Confirm that there are no leaks, then turn off pump and power off to the unit. Reinstall lamps, spring clip and connect to ballast(s).
  • Page 16: Scheduled Uv Lamp(S) Replacement

    2½ years of operation, they have reached the end of their useful life. Turn off all power to the Ultra UV2 unit and all other pool equipment. Unplug the unit from its power receptacle or turn OFF the circuit breaker that is the Ultra UV2’s power source.
  • Page 17: Faqs

    FAQs Is the Ultra UV2 unit designed for use in salt water applications? Yes. Paramount’s Ultra UV2 units are fully compatible with all salt water environments. The quartz tube could require more frequent cleaning in a salt water environment. Do I need to turn my Ultra UV2 unit off when I backwash my filter? No.
  • Page 18: Troubleshooting

    Make sure the system filter and all debris baskets are clean. Verify that the Ultra UV2 unit is operating at a minimum of 2psi, which is required to acti- vate the pressure switch. Please note that the filter gauge does not indicate the pressure in the UV unit.
  • Page 19 The Water is Green Green water is an indication that the UV rays generated by the Ultra UV2 unit are not effective or are not being generated by the UV lamp(s). Check the lamp(s) to make sure all lamps in your system are ON (by viewing the lamp(s) through the clear viewing band on the center of the reactor.
  • Page 20: Specification Notice

    Reset the GFCI and if it does not trip, attach the electrical plug to a UV lamp (one at a time if multiple lamps are present in your Ultra UV2 unit). If it trips with the lamp lit, it indicates that a UV lamp is causing the fault to ground.
  • Page 21: Head Loss Curves

    Head Loss Curves USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
  • Page 22: Replacement Parts

    Replacement Parts Optional Flow Switch Optional Flow Switch USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
  • Page 23 Ultra UV2 Replacement Part Numbers Pararmount Part # Description 005-422-2009-11 Cover 005-422-9017-00 UV Lamp Spring Clip UV Lamp Holder 005-422-5102-00 Quartz Tube Sealing Assembly 005-422-9030-00 Universal Ballast Replacement Kit 005-422-5103-00 Quartz Tube Seal O-ring, 3-Pack 005-422-2009-10 Pressure Switch 005-422-2009-06 2" Union Kits...
  • Page 24 Ultra UV2 is a registered trademark of Hayward Industries, Inc. © 2023 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
