004-027-8886-00 R00
ECN_2361 PUB021523
Paralevel
Automatic Water Leveler
Start Up Manual
Contents
Overview.................................1
Start Up..................................2
Winterization..........................4
Identify Paralevel Model..........5
Use New Float in Old Tank........6
Replacement Parts..................7
Paramount
8175 W. Buckeye Rd.,
Phoenix, AZ 85043
Phone: (480) 893-7607
www.1Paramount.com
USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Paramount Fitness Paralevel
Summary of Contents for Paramount Fitness Paralevel
-
Page 1: Table Of Contents
ECN_2361 PUB021523 Paralevel Automatic Water Leveler Start Up Manual Contents Overview.........1 Start Up........2 Winterization......4 Identify Paralevel Model..5 Use New Float in Old Tank..6 Replacement Parts....7 Paramount 8175 W. Buckeye Rd., Phoenix, AZ 85043 Phone: (480) 893-7607 www.1Paramount.com USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS... -
Page 2: Overview
The balance line must be plumbed with 11/2” pipe. The water line can be plumbed with 1/2” or ¾” pipe. The Paralevel can also be plumbed with 11/2” pipe for overflow protection. -
Page 3: Start Up
Start Up Installation Steps Make sure the water supply line is turned off at the Seal Plug valve. Fig. 1 Remove plugs. • Use the Removal Tool to remove the 1 1/2” NPT Cap. • Use a 3/8” socket extension to remove the 1/2”... - Page 4 Turn on water supply at source fully. The Paralevel has anti-water hammer feature as part of its smart sensing. The Paralevel works best at full pressure • Fill the pool until the water level is just below center of tile with less than 1” left to fill.
-
Page 5: Winterization
Paralevel exploded parts diagram. (page 6) Drain the water in the pool to below the opening for the equalizer line for the Paralevel. Place the O-ring and Seal Plug #4 and #5 on the winterizing kit exploded parts diagram (page 7) into the threaded hole that the Flow Plug was removed from. -
Page 6: Identify Paralevel Model
Retainer Nut was removed from to collect the water blown into the Paralevel housing. When the line is clear place the Cap Seal and Main seal #1 and #3 on the winterizing kit exploded parts diagram (page 7) over this opening. It is recommend that the disconnected water line at the house be taped shut or sealed when disconnected so insects and debris don’t get in the line. -
Page 7: Use New Float In Old Tank
Use New Float in Old Tank While holding the new float, twist sleeve Fig. 12 counter clockwise until it comes out of the float. Turn float over and re-thread on sleeve with flat side up. Be careful not to cross-thread (Fig. -
Page 8: Replacement Parts
Adjuster Sleeve 004-552-5452-00** Tool Float Body 004-760-2921-00 Start Up Kit B 005-761-2934-00** Extension 1" Part of Item #24 Top Lever 005-762-2932-00 Linkage Replacement Kit *Parts are not available separately **Not part of Paralevel. Order Separately. USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS... - Page 9 Adjuster Sleeve 004-552-5452-00** Tool Float Body 004-760-2921-00 Start Up Kit B 005-761-2934-00 Extension 1" Part of Item #24 Top Lever 005-762-2932-00 Linkage Replacement Kit *Parts are not available separately **Not part of Paralevel. Order Separately. USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
- Page 10 Paralevel Winterizing/Pressure Test Kit 005-760-2911-00 Part Number Description 005-760-2901-00 Winterization/Pressure Test Kit 1/2" NPT Cap Main Seal Cap Seal Seal Plug O-Ring 2-020 EP70 USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
- Page 11 USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
- Page 12 Paralevel is a registered trademark of Hayward Industries, Inc. © 2023 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
