S PRI NTER ST EP E XT EN SI ON
SP1001 B
INSTALLATION
GUIDE
F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6
TOOLS REQUIRED
(NOT INCLUDED)
+
7/16" WRENCH OR SOCKET
+
#2 PHILLIPS SCREWDRIVER
+
IMPACT DRIVER OR DRILL
INSTALL INFO
TIME TO INSTALL THIS PRODUCT: 30-45 MINUTES
Additional help is suggested for a few of the install steps.
Compatible with all FVC Rear Door Platforms.
BEFORE YOU START
Please inspect the product and packaging upon
delivery to ensure there are no issues and that
all parts and hardware are accounted for.
Contact us ASAP if anything is missing at:
support@flatlinevanco.com
0 1
Advertisement
Related Manuals for FVC SP1001B
Summary of Contents for FVC SP1001B
- Page 1 INSTALL INFO TIME TO INSTALL THIS PRODUCT: 30-45 MINUTES Additional help is suggested for a few of the install steps. Compatible with all FVC Rear Door Platforms. BEFORE YOU START Please inspect the product and packaging upon delivery to ensure there are no issues and that all parts and hardware are accounted for.
-
Page 2: Before You Start
BEFORE YOU START All Flatline Van Co products must be properly assembled and secured before attaching to your vehicle. Improper attachment could result in an automobile accident, and could cause serious bodily injury or death to you or to others involved. You are responsible for assembling and securing Flatline Van Co products to your vehicle, checking the mounting points and attachments prior to use, and regularly inspecting the products for wear and or damage. -
Page 3: Package Contents
PACKAGE CONTENTS FLOOR SUPPORT EXTENSION FLOORING EXTENSION SUPPORT BRACKET STEP EXTENSION TRIM QTY: 1 QTY: 1 QTY: 1 QTY: 1 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6... - Page 4 HARDWARE #6 X 0.375 FLAT HEAD #8 X 0.625 FLAT HEAD 6-32 X 0.625 FLAT HEAD 6-32 NYLON INSERT PHILLIPS DRIVE SCREW DRILLING SCREW PHILLIPS DRIVE SCREW LOCKNUT QTY: 12 QTY: 7 QTY: 8 QTY: 8 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6...
- Page 5 INSTALL TOOLS REQUIRED FOR THIS STEP: STEP | 01 LAYOUT AND INSTALL PREP 1.1 Dry Fit The Floor Support Extension: Place the Floor Support Extension on the left side of the factory step (FIG 1) and ensure alignment along the front side (FIG 2) matches the contours of the back side (FIG 3).
- Page 6 INSTALL TOOLS REQUIRED FOR THIS STEP: STEP | 01 LAYOUT AND INSTALL PREP 1.2 Confirm Fitment With The Step Extension Trim: Dry fit the Step Extension Trim to the Support Extension (FIG 4) and ensure that the bends align (FIG 5) and that all mounting holes are aligned (FIG 6) before proceeding to installation.
- Page 7 #2 PHILLIPS SCREWDRIVER TOOLS REQUIRED FOR THIS STEP: STEP | 02 INSTALL SUPPORT EXTENSION 2.1 Install the Floor Support Extension: Use (4) #8 Flat Head Drilling Screws (FIG 7-9) to secure the Floor Support Extension to the plastic of the factory step. NOTE - Hold the extension firmly in place to maintain alignment while driving in the screws F I G 7...
- Page 8 7/16” WRENCH OR SOCKET TOOLS REQUIRED FOR THIS STEP: #2 PHILLIPS SCREWDRIVER STEP | 03 ASSEMBLE SUPPORT BRACKET 3.1 Attach the Wood Flooring Extension to the Support Bracket: Bolt the wood Flooring Extension and Support Bracket together with (3) 6-32 X 0.625 Flat Head Phillips Drive Screws and 6-32 Nylon Locknuts (FIG 9).
- Page 9 TOOLS REQUIRED FOR THIS STEP: #2 PHILLIPS SCREWDRIVER IMPACT DRIVER OR DRILL STEP | 04 FLOOR INSTALL & ALIGNMENT 4.1 Loosely Attach Support Bracket Assembly to Flooring Extension: Take the Support Bracket Assembly and lay it down on top of the Floor Support Extension (FIG 11). Insert (2) 6-32 X 0.625 Flat Head Phillips Drive Screws in the locations shown in FIG 12 to ensure alignment of the pre-drilled holes.
- Page 10 7/16” WRENCH OR SOCKET TOOLS REQUIRED FOR THIS STEP: #2 PHILLIPS SCREWDRIVER STEP | 05 FINISH INSTALL 5.1 Secure the Flooring Extension to the Flooring Support Extension: Use the remaining 6-32 Flat Head Phillips Screws and Nylon Locknuts to secure the Support Bracket Assembly to the Flooring Support Extension (FIG 14).
- Page 11 FVC (and see) from you! Head to the products and following along and we will make it right. FVC is product page and click “Leave a company of van and outdoor with your adventures. Tag us Review.”...
