Table 4: IA-A-25 Environmental Specifications (continued)
Parameter
Shock, operating
Shock, unpackaged
Shock, packaged
ESD
Estimated thermal dissipation

Front Panel Features

Figure 1
shows the front panel features.
Figure 1: IA-A-25 Front Panel Features
A
System label pull-out
B
Video Connector
C
USB 3.0 Ports
Figure 2: Front Control Panel
A
System ID button w/integrated LED
B
NMI button (recessed, tool required for use)
ExtremeControl IA-A-25 Installation Guide for version 8.1
Limits
Half sine, 2 g-force peak, 11 milliseconds
Trapezoidal, 25 g, velocity change 136 inches/second (40 lb to < 80
lb)
Non-palletized free fall in height 24 inches (40 lb to < 80 lb)
±12 KV except I/O port ±8 KV per Intel® Environmental test
specification
1550 BTU/Hr
Figure 2
on page 8 shows the front control panel.
D
Front control panel (see
E
Hard disk drive bays
F
G
Engine Overview and Setup
Figure 2
on page 8)
System status LED
Power button w/integrated LED
8
