  • Page 1 Extreme Networks Universal Compute Platform 1130C Installation Guide Setup, Configuration, and Compliance 9038032-00   Rev AA August 2024...
  • Page 2 Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
  • Page 3: Table Of Contents

    Conformitè Europëenne (CE) Notice..........................22 Japan (VCCI) - Voluntary Control Council for Interference Class A ITE...........22 BSMI Statement - Taiwan................................22 CCC Statement - China................................24 Supplement to Product Instructions..........................24 Hazardous Substances.................................24 Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 4 Table of Contents European Waste Electrical and Electronic Equipment (WEEE) Notice..........25 Index..............................26 Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 5: Preface

    When a feature, function, or operation pertains to a specific hardware product, the product name is used. When features, functions, and operations are the same across an entire product family, such as Extreme Networks switches or SLX routers, the product is the switch or the router .
  • Page 6 You must select one of the options. A vertical bar separates mutually exclusive elements. x | y Nonprinting characters, such as passwords, are enclosed in < > angle brackets. Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 7: Documentation And Training

    Some software files have been licensed under certain open source licenses. Information is available on the Open Source Declaration page. Training Extreme Networks offers product training courses, both online and in person, as well as specialized certifications. For details, visit the Extreme Networks Training page. Help and Support...
  • Page 8: Subscribe To Product Announcements

    You can modify your product selections or unsubscribe at any time. Send Feedback The User Enablement team at Extreme Networks has made every effort to ensure that this document is accurate, complete, and easy to use. We strive to improve our documentation to help you in your work, so we want to hear from you.
  • Page 9: Overview

    Front and Back Panel Information on page 10 The Extreme Networks 1130C is a cloud-based Universal Compute Platform for small deployments, such as small businesses, clinics, or schools. It fits a 19-inch rack and features four data ports, two USB ports, and two Inter-Cluster-Connect ports.
  • Page 10: Ports

    One RJ45 Console port • Two USB 3.0 ports • Four GbE Ethernet ports LEDs The 1130C has an LED for power on the front of the chassis. Power The 1130C power specifications are as follows: • 150 watts •...
  • Page 11 Overview Front and Back Panel Information Figure 1: 1130C Front Panel Layout The 1130C has the following hardware features located on the front panel. Table 4: 1130C Front Panel Callout Description Power LED RJ45 Console port USB 3.0 port 1 USB 3.0 port 2...
  • Page 12 Front and Back Panel Information Overview Table 5: 1130C Back Panel (continued) Callout Description Plug On/Off switch Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 13: Installation

    14 Connect to a Power Source on page 15 Use the information in the following sections to install the 1130C appliance. Installation Workflow The following table lists the installation tasks. Use this information as a guide when you install the 1130C.
  • Page 14: Verify The Box Contents

    Installation Verify the Box Contents About This Task The 1130C ships with everything needed for a basic installation. Confirm that you have received the following items before you install your appliance. Note The power cord must be purchased separately for the respective country where you are deploying the device.
  • Page 15: Connect To A Power Source

    2. Plug the power cable into a grounded electrical outlet or a power source such as an uninterrupted power supply (UPS) or a power distribution unit (PDU). 3. Power on the appliance. The power switch is on the back panel. Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 16: Configuration

    • Data plane settings About This Task You can configure the 1130C appliance from the appliance console port if you have physical access to it. Configuration is asynchronous, but you can see the boot up process. The console port is on the appliance's front panel. See Front and Back Panel Information.
  • Page 17 10. Enter admin and the credentials that were created when setting up the installation wizard. Note An installation wizard is available to help configure the 1130C for new deployments. For more information, see ExtremeCloud Edge – Self- Orchestration Deployment Guide for Universal Compute Platform.
  • Page 18: Configure The Management Interface From The Inter-Cluster-Connect Port

    Connect the Data Ports About This Task 1130C Ethernet ports 1 - 4 are 1 GbE RJ45 ports. Ensure that the device to be connected at the other end of the segment is powered on. To connect a twisted pair cabling: Procedure 1.
  • Page 19: Ethernet Ports Led Information

    1,000 Mbps (1 Gbps) Link activity (right) No link Solid green Active link Blinking green Data traffic activity Blinking amber Disconnect (appliance was shut down, power switch is still in on position) Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 20: Regulatory And Compliance Information

    European Waste Electrical and Electronic Equipment (WEEE) Notice on page 25 The following sections detail the regulatory information for the 1130C appliance. Safety Guidelines Learn about the safety guidelines that are intended to protect your personal safety and prevent damage to the equipment.
  • Page 21: Battery Notice

    “Digital Apparatus,” ICES-003 of the Canadian Department of Communications. Cet appareil numérique respecte les limites bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 22: Conformitè Europëenne (Ce) Notice

    BSMI Statement - Taiwan This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 23 Regulatory and Compliance Information BSMI Statement - Taiwan Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 24: Ccc Statement - China

    This product complies with the requirements of Directive 2011/65/EU and its amendments of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment. Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 25: European Waste Electrical And Electronic Equipment (Weee) Notice

    4. It is the user's responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please contact Extreme Environmental Compliance at Green@extremenetworks.com. Extreme Networks Universal Compute Platform 1130C Installation Guide...
  • Page 26 14 work flow 13 technical support contacting 7, 8 Industry Canada Notice 21 Installation 13 interface warnings 5 1130C configuration 16 console port 16 management interface 16 Extreme Networks Universal Compute Platform 1130C Installation Guide...
