At the end of the setup process, the existing settings will be displayed and
opportunity will be provided to correct any errors.
=================================================================
Press [enter] to begin setup or CTRL-C to exit:
2 Press [Enter] to begin the setup.
The Root Password Configuration screen appears:
=================================================================
Root Password Configuration
=================================================================
There is currently no password set in the system administrator
account (root). It is recommended that you set one that is active
the first time the machine is rebooted.
=================================================================
Would you like to set a root password (y/n) [y]?
3 Press [Enter] to set a new root password. Enter the new password as prompted.
Enter new UNIX password:
Retype new UNIX password:
Password updated successfully.
4 In the Access Control Engine Configuration screen, enter the requested information for each line and
press [Enter].
=================================================================
Access Control Engine Configuration
=================================================================
Enter the hostname for the engine [nacappliance]:
Please enter the IP address for nacappliance (Required): 10.15.76.100
Enter the IP netmask [255.255.255.0]:
Enter the engine address [10.50.76.1]:
Enter the IP address of the name server (Optional): 1.2.3.4
Enter the IP address of an alternate name server (Optional): 1.2.3.4
Enter the domain name for nacappliance (Required): extremenetworks.com
Enter the IP address of the NetSight Server (Required): 1.3.4.5^\
5 In the SNMP Configuration screen, enter the requested information for each line and press [Enter].
=================================================================
SNMP Configuration
=================================================================
The following information will be used to configure SNMP management of this device. The
SNMP information entered here must be used to contact this device with remote
management applications such as Extreme Management Center Console.
=================================================================
Please enter the SNMP user name [snmpuser]:
Please enter the SNMP authentication credential [snmpauthcred]:
Please enter the SNMP privacy credential [snmpprivcred]:
6 In the Configure Date and Time Settings screen, select whether you want to use an external Network
Time Protocol (NTP) server. Enter y to use NTP, and enter your NTP server IP address(es). Enter n to
configure the date and time manually and proceed to step 8.
=================================================================
Configure Date And Time Settings
