Torque Values
The following table describes the recommended torque values to use when installing the engine using
standard threaded fastener machine screws and bolts.
Table 9: Recommended Torque Values by Screw Size
Screw Size
English
N/A
2 – 56
4 – 40
6 – 32
8 – 32
10 – 32
1/4 – 20
ExtremeControl IA-A-25 Installation Guide for version 8.1
Torque in Pounds
Metric -%5
N/A 1.42
1.5 2.85
2.5 4.75
3.5 8.55
4.5 17.10
5 30.40
6.5 63.65
Engine Overview and Setup
Nominal +%5
1.5 1.57
3.0 3.15
5.0 5.25
9.0 9.45
18.0 18.90
32.0 33.60
67.0 70.35
Bit Size
0
0
0/1
1
2
2
3
