  • Page 1 IA-A-20 and IA-A-300 Installation Guide ® NetSight Identity and Access Appliance 9034888 Published July 2015...
  • Page 2 Copyright © 2011–2015 All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
  • Page 3: Table Of Contents

    Pre-Configuration Tasks..............................14 Configuring the Appliance..............................14 Changing Appliance Settings............................18 Upgrading Appliance Software..........................20 Chapter 3: Reinstalling Appliance Software................ 21 Appendix A: Product Regulatory and Compliance Information........22 ® Appendix B: Extreme Networks License Agreement............27 IA-A-20 and IA-A-300 Installation Guide...
  • Page 4: About This Guide

    About this Guide This document describes the installation and initial configuration of the Extreme Networks ® Identity and Access IA–A–20 and IA–A–300 hardware appliances. This document is intended for experienced network administrators who are responsible for implementing and maintaining communications networks.
  • Page 5: Providing Feedback To Us

    Ideas for improvements to our documentation so you can find the information you need faster. • Broken links or usability issues. If you would like to provide feedback to the Extreme Networks Information Development team about this document, please contact us using our short online feedback form.
  • Page 6: Related Publications

    For complete regulatory compliance and safety information, refer to the document Intel ® Server Products Product Safety and Regulatory Compliance. Other Documentation • ExtremeXOS Command Reference Guide • ExtremeXOS Release Notes • ExtremeXOS User Guide IA-A-20 and IA-A-300 Installation Guide...
  • Page 7: Chapter 1: Appliance Overview And Setup

    One USB flash drive Specifications The physical specifications for the appliances are listed in the table below. The environmental requirements are listed in Table 4: IA-A-20 and IA-A-300 Environmental Specifications on page 9. Table 3: IA-A-20 and IA-A-300 Physical Specifications Processor Processor type IA-A-20 - Intel®...
  • Page 8 Appliance Overview and Setup Table 3: IA-A-20 and IA-A-300 Physical Specifications (continued) Processor speed 2.0 GHz Internal cache 15 MB per processor System bus speed 7.20 GT/s (Gigatransfers per second) System bus type QPI (Quick Path Interconnect) Memory Architecture 1333MHz Dual Ranked Registered (RDIMM) ECC DDR3...
  • Page 9: Front Panel Features

    Figure 2: Front Control Panel on page 10 shows the front control panel. Figure 1: IA-A-20 and IA-A-300 Front Panel Features A System label pull-out C Front control panel (see Figure 2: Front Control Panel on page 10) B USB 2.0 port...
  • Page 10: Back Panel Features

    Table 6: Hard Drive Status LED Indicator Patterns Hard Drive Condition Status LED Patterns No access or no fault Hard drive fault has occurred Solid amber Back Panel Features The figure below shows the back panel. IA-A-20 and IA-A-300 Installation Guide...
  • Page 11 Appliance Overview and Setup Figure 3: IA-A-20 and IA-A-300 Back Panel Power supply module #1 Video connector Power supply module #2 Not used eth0, Mgmt Port, 1 GbE RJ45 USB 2.0 ports eth1 Not used eth2 Not used eth3 Not used The following table describes the LEDs for the RJ45 management port.
  • Page 12: Removing And Installing The Front Bezel

    Refer to the installation guide for complete installation instructions. If you are table mounting the appliance, ensure at least 6 cm of clearance on all sides of the appliance for proper ventilation. If you are installing the appliance in a rack: IA-A-20 and IA-A-300 Installation Guide...
  • Page 13 1.42 1.57 2 – 56 2.85 3.15 4 – 40 4.75 5.25 6 – 32 8.55 9.45 8 – 32 17.10 18.0 18.90 10 – 32 30.40 32.0 33.60 1/4 – 20 63.65 67.0 70.35 IA-A-20 and IA-A-300 Installation Guide...
  • Page 14: Chapter 2: Configuration

    Figure 1: IA-A-20 and IA- A-300 Front Panel Features on page 9 and Figure 3: IA-A-20 and IA-A-300 Back Panel on page 11). After the appliance boots and the appliance installation is complete, you must go through the initial configuration process described in this chapter.
  • Page 15 The SNMP information entered here must be used to contact this device with remote management applications such as NetSight Console. ================================================================= Please enter the SNMP user name [snmpuser]: Please enter the SNMP authentication credential [snmpauthcred]: Please enter the SNMP privacy credential [snmpprivcred]: IA-A-20 and IA-A-300 Installation Guide...
  • Page 16 - 2 digit minute of hour ss - 2 digit seconds ================================================================= Please enter the month [06]: Please enter the day of the month [24]: Please enter the year [2013]: Please enter the hour of day [09]: IA-A-20 and IA-A-300 Installation Guide...
  • Page 17 0. Accept the current settings 1. Edit NAC Appliance settings 2. Edit SNMP settings 3. Edit date and time 4. Modify all settings ================================================================= Enter selection [0]: When you see the following screen, configuration is complete. IA-A-20 and IA-A-300 Installation Guide...
  • Page 18: Changing Appliance Settings

    Configuration ================================================================= Extreme Networks - Network Access Control Appliance - Setup Complete ================================================================= Setup of the NAC Appliance is now complete. Details of the appliance setup process are located in the log files in the /var/log/install directory. ================================================================= You are now ready to use NAC Manager to manage your appliance. If this is your initial commissioning of the appliance, you can launch NAC Manager and view the Getting Started video available on the Welcome tab.
  • Page 19 In the event that you need to manually change the web service credentials on the appliance, enter the following command at the appliance CLI: /opt/nac/configWebCredentials <username> <password> Then, restart the appliance by typing: nacctl restart IA-A-20 and IA-A-300 Installation Guide...
  • Page 20: Upgrading Appliance Software

    Instructions for performing the software upgrade are also available on the NetSight (NMS) web page. Click on the Documentation tab and follow this path to the document: Manuals & Release Notes > select a version of NetSight > Network Access Control (NAC). IA-A-20 and IA-A-300 Installation Guide...
  • Page 21: Chapter 3: Reinstalling Appliance Software

    Successfully installed into <drive letter>: Press any key to continue. 5 Remove the USB flash drive from your system. 6 Insert the USB flash drive into a USB port on the appliance (see Figure 1: IA-A-20 and IA-A-300 Front Panel Features on page 9).
  • Page 22: Appendix A: Product Regulatory And Compliance Information

    003 of the Canadian Department of Communications. Cet appareil numérique respecte les limites bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques”, NMB-003 édictée par le Ministre Canadian des Communications. IA-A-20 and IA-A-300 Installation Guide...
  • Page 23 Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2012/19/EU of the European Parliament on waste electrical and electronic equipment (WEEE): IA-A-20 and IA-A-300 Installation Guide...
  • Page 24 4 It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please contact Enterasys Customer Support at +353 61 705500 (Ireland). IA-A-20 and IA-A-300 Installation Guide...
  • Page 25 Product Regulatory and Compliance Information Declaration of Conformity Application of Council Directive(s): 2004/108/EC 2006/95/EC 2011/65/EU Manufacturer’s Name: Extreme Networks, Inc. IA-A-20 and IA-A-300 Installation Guide...
  • Page 26 The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment. IA-A-20 and IA-A-300 Installation Guide...
  • Page 27: Appendix B: Extreme Networks License Agreement

    ® Agreement This document is an agreement (“Agreement”) between You, the end user, and Extreme Networks, Inc., on behalf of itself and its Affiliates (“Extreme”) that sets forth your rights and obligations with respect to the “Licensed Materials”. BY INSTALLING SOFTWARE AND/OR THE LICENSE KEY FOR THE SOFTWARE (“License Key”) (collectively, “Licensed Software”), IF APPLICABLE, COPYING, OR...
  • Page 28 Agreement, You may not copy or otherwise reproduce the Licensed Materials. In no event does the limited copying or reproduction permitted under this Agreement include the right to decompile, disassemble, electronically transfer, or reverse engineer the Licensed Materials, IA-A-20 and IA-A-300 Installation Guide...
  • Page 29 Extreme. You acknowledge that the Licensed Materials contain valuable confidential information and trade secrets, and that unauthorized use, copying and/or disclosure thereof are harmful to Extreme or its Affiliates and/or its/their software suppliers. IA-A-20 and IA-A-300 Installation Guide...
  • Page 30 Use. 12 UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The Licensed Materials (i) were developed solely at private expense; (ii) contain “restricted computer software” submitted with restricted IA-A-20 and IA-A-300 Installation Guide...
  • Page 31 Licensed Materials and are further available for review at www.extremenetworks.com/services/ SoftwareLicensing.aspx, or upon request as directed herein. In accordance with the terms of the GPL and LGPL, you may request a copy of the relevant source code. See the Software Licensing IA-A-20 and IA-A-300 Installation Guide...
  • Page 32 Any notice or other communication to be sent to Extreme must be mailed by certified mail to the following address: Extreme Networks, Inc. 145 Rio Robles San Jose, CA 95134 United States ATTN: Legal Department IA-A-20 and IA-A-300 Installation Guide...
