9.5

Configuration Lab 845

9.5.1 Basic settings

Via (CONF) you will go to the menu item "Configuration".
The entire structure of the menu (CONF) is displayed graphically in  9.4.
The following device-relevant basic settings can be configured:
data logg.
temperature
Sensortype
general.

9.5.2 Configuration of the fixed temperature

As the pH measured value is always temperature-compensated, the temperature of the measuring
and calibration media must be measured or set up as a fixed temperature.
If the fixed temperature is activated, it is used for temperature compensation.
> The message "FIX" will appear in the top right side of the display.
> Configuration of the fixed temperature:
"Temperature" > "Fixed temperature"
"Temperature" > "Temp. value"
Via (INFO) or (CAL) you select the position to change.
Via (CONF +1) or (LOG -1) you change the position.
(ON/OFF) confirms and saves your setting.
(MEAS) terminates the entry dialog without transferring the value.

9.5.3 Configuration of the sensor type

3 different sensor types can be connected to the Lab 845.
pH
ORP
ISE
Sensor selection:
Select "Sensor type" >, then Type.
Via (CONF +1) or (LOG -1) you selected the desired setting.
(ON/OFF) confirms and saves your setting.
(MEAS) terminates the entry dialog without transferring the value.

Data logger ( Chapter 5)

Temperature

Sensortype

General ( Kapitel 4)
, then select the fixed temperature value.
>
, then select activate / deactivate.
>
59
