54
8.5

Configuration Lab 745

8.5.1 Basic settings

Via (CONF) you will go to the menu item "Configuration".
The entire structure of the menu (CONF) is displayed graphically in  8.4.
The following device-relevant basic settings can be configured:
data logg.
temperature
main value
general

8.5.2 Configuration of the fixed temperature

As the oxygen measured value timer is temperature-compensated, the temperature of the measuring
and calibration media must be measured or saved as a fixed temperature.
If the fixed temperature is activated, it is used for temperature compensation.
> The message "FIX" will appear in the top right side of the display.
> Configuration of the fixed temperature:
"Temperature" > "Fixed temperature"
"Temperature" > "Temp. value"
Via (INFO) or (CAL) you select the position to change.
Via (CONF +1) or (LOG -1) you change the position.
(ON/OFF) confirms and saves your setting.
(MEAS) terminates the entry dialog without transferring the value.

8.5.3 Configuration of "Main display"

The main measured value and the secondary measured value can be switched on the meter.
If not specified otherwise, the factory setting is the main measured value as the oxygen saturation
in % and the secondary measured value is set as the oxygen concentration in mg/l.
> Configuration of the main measured value:
"Main display" >, then select the measured value.
Main measured value
%
Saturation in %
mg/l Concentration in mg/l
Via (CONF +1) or (LOG -1) you selected the main measured value.
(ON/OFF) confirms and saves the input value.
(MEAS) terminates the entry dialog without transferring the value.

Data logger ( Chapter 5)

Temperature

main value

General ( Chapter 4)
, select the fixed temperature value.
>
Secondary measured value
Concentration in mg/l
Saturation in %
, select activate / deactivate
>
