LED Indicators

LED
User
Internet
Link
RX/TX
I/O 1
I/O 2
Connectivity - Port Settings
When connecting to most routers, the IP150+MQ will automatically connect, and nothing needs to be configured.
Should you have issues connecting, please make sure that the ISP, router/firewall is not blocking the following ports.
They need to be permanently open (TCP/UDP, and inbound and outbound).
Port
UDP 53
UDP 123
UDP 5683
TCP 8883
TCP 443
TCP Port 465, 587

Creating a Site

1) Open the BlueEye app.
2) Select the Menu, and then select Installer Menu.
3) Press on the 3-dot menu and select Create New Site.
4) Enter the Panel SN, Site Name, and email address.
5) Tap on Create New Site.
6) Site is created.
Description
Green - On when a user is connected via BlueEye/BabyWare/InField/
NEware.
ON - Connected to Internet and connected to Swan-Q.
Flashing every 1 second - connected to Internet, not connected to Swan-Q
(no site token).
OFF - no internet
ON - Connected to Ethernet (GREEN 100mbps Orange 10mbps)
ON - when connected to panel
Flashes when data is transmitted or received through/from panel.
OFF when no connection to panel.
N/A
N/A
Description (used for)
DNS
NTP
COAP (back up)
MQTT port SWAN and IPC10 receiver
OTA (firmware upgrade + certificate download)
Usually for email server, may differ depending on the email server used.
