  • Page 1 Wireless Expansion Module V1.0 Reference & Installation Manual MG-RCV3 (DGP-848 / DGP-NE96)
  • Page 3: Table Of Contents

    About Programming .................7 Spectra Programming ..................8 Digiplex Series Programming ................8 Transmitter Programming ...............8 Assign the Transmitters to the MG-RCV3 ............9 Delete the Assigned Transmitters ..............10 Display Options ..................11 View a Transmitter’s Unknown Serial Number ..........11 View a Transmitter’s Signal Strength ..............
  • Page 4 Programmable Outputs (PGMs) ............20 PGM Connection ....................20 PGM Activation ....................20 PGM Deactivation .................... 20 Remote Control Programming ............. 21 Assign a Remote Control to the Magellan Module ........... 22 View the Assigned Remote Controls (Digiplex Series only) ....... 23 Delete an Assigned Remote Control ..............
  • Page 5: Introduction

    Digiplex series (DGP-848 or DGP-NE96) security system. The MG-RCV3 is available in either a 433MHz or 868MHz version. When connected to a Spectra system, the MG-RCV3 allows you to add up to eight Magellan wireless transmitters, and up to eight fully programmable Magellan remote controls. When...
  • Page 6: System Features

    • Transmitter signal strength indicator • Transmitter battery life display (Digiplex series only) 2.0 Installation The following sections will detail how to mount and connect the MG-RCV3. 2.1 Location The locations of the MG-RCV3 and wireless transmitters affect the overall performance of the wireless system.
  • Page 7: Noise Level Test

    • Mount the MG-RCV3 as high as possible • Avoid mounting the MG-RCV3 in the basement as the range of the module is reduced when mounted below ground level. However, if it is absolutely necessary to mount the module in the basement, mount the module as high and as close to the underside of the first floor as possible •...
  • Page 8: Programming A Wireless Fire Zone With A Spectra System

    Do not cut, bend, or alter the antenna. Ensure that the electrical wires do not cross over the antenna when connected. For Spectra systems, do not connect more than one MG-RCV3 to the control panel. The MG-RCV3 does not function with control panels that have a built-in wireless receiver, such as the Spectra 1759MG.
  • Page 9: List Of Figures Mounting

    1. The zone must be defined as a 24Hr Burglary zone 2. The zone’s alarm type must be set to Audible Alarm (pulsed) 3. The zone’s Auto-Zone Shutdown (zone option [1]) and Bypass (zone option [2]) features must be disabled. 4.
  • Page 10: Connecting Magellan To The Control Panel

    Figure 2.2: Connecting Magellan to the Control Panel Reference & Installation Manual...
  • Page 11: About Programming

    3.0 About Programming The following steps must be completed in order to successfully install a MG-RCV3 to a Spectra or Digiplex series system. 1. Temporarily mount the MG-RCV3 in its proposed location (refer to section 2.3 on page 3). 2. Assign the remote controls (refer to section 8.0 on page 21).
  • Page 12: Spectra Programming

    6. Enter the required [ DATA 4.0 Transmitter Programming For Spectra systems, up to eight transmitters can be assigned to each MG-RCV3. Digiplex series systems support up to 16 transmitters. The following tables display the interrelated transmitter sections: Table 4.1: Interrelated Spectra Transmitter (Tx) Sections...
  • Page 13: Assign The Transmitters To The Mg-Rcv3

    For example, do not assign a wireless transmitter to section [601], then connect a detection device to input Z1 of the APR3-ZX8. How to assign the transmitters to a MG-RCV3: Spectra Sections [601] to [608] represent expansion inputs 1 to 8 respectively. For example, section [601] is assigned to expansion input 1 and section [602] is assigned to expansion input 2.
  • Page 14: Delete The Assigned Transmitters

    Digiplex Series Sections [101] to [116] represent inputs 001 to 016 respectively. For example, section [101] is assigned to input 001 and section [102] is assigned to input 002. In step 5 in section 3.2 on page 8: 1. Enter a section number between [101] and [116]. 2.
  • Page 15: Display Options

    5.0 Display Options View the following transmitter information: • A transmitter’s unknown serial number • A transmitter’s signal strength • A transmitter’s current battery life (Digiplex series only) • A transmitter’s previous battery life (Digiplex series only) 5.1 View a Transmitter’s Unknown Serial Number [630] PECTRA SECTION...
  • Page 16: View A Transmitter's Signal Strength

    [616] IGIPLEX SERIES SECTIONS Once the transmitters have been assigned to the MG-RCV3, the signal strength of each transmitter can be verified in these sections. For Spectra systems, you can also use a keypad’s beep sequence to determine a transmitter’s signal strength (refer to section 5.2.1 on page 13).
  • Page 17: Signal Strength Keypad Beep Tones (Spectra Only)

    5.2.1 Signal Strength Keypad Beep Tones (Spectra only) You can also use the MG-RCV3’s beep sequence feature to verify a transmitter’s signal strength (refer to section 5.2 on page 12). When you press a transmitter’s anti-tamper switch or open the corresponding zone, beep tones emanating from all the keypads connected to the communication bus will advise you of the transmitter’s signal strength.
  • Page 18: View Transmitter's Previous Battery Life (Digiplex Series Only)

    section represents the current battery life reading of a specific transmitter. For example, section [701] is the actual battery life reading for the transmitter assigned in section [101], and section [716] is the reading for the transmitter assigned in section [116]. How to view a transmitter’s current battery life: In step 5 in section 3.2 on page 8: 1.
  • Page 19: Supervision Options

    For Digiplex series systems, option [1] enables the Low Battery Supervision feature. When a transmitter’s battery voltage drops below a recommended level, its red LED will flash and it will transmit a signal to the MG-RCV3 indicating that the voltage is low. If this option is enabled, the MG-RCV3 will...
  • Page 20: Check-In Supervision

    IGIPLEX SERIES SECTION OPTION With check-in supervision enabled, the MG-RCV3 waits for each of its assigned transmitters to send a status signal within a specified time period to confirm their presence and functionality. If a transmitter has not sent a signal within that time period, the module will transmit a supervision loss signal to the control panel.
  • Page 21: Tamper Supervision

    (refer to Figure 2.2 on page 6) will be triggered. When this occurs, the MG-RCV3 will send a tamper signal to the control panel. The control panel can then generate a trouble, an alarm and/or can transmit a report code to the monitoring station.
  • Page 22: On-Board Module Tamper Supervision Zone Assignment (Spectra Only)

    [615]: 000 PECTRA SECTION Unlike when connected to a Digiplex series system, a MG-RCV3 that is connected to a Spectra system communicates a module tamper report through one of the module’s expansion inputs. This feature determines the expansion input that will be used for the tamper supervision. When...
  • Page 23: On-Board Module Tamper Supervision (Digiplex Series Only)

    IGIPLEX SERIES SECTION OPTION With this feature disabled, the MG-RCV3 will disregard any tamper signals coming from any of its assigned wireless transmitters. As a result, the MG- RCV3 will not send a tamper signal to the control panel therefore not generating a trouble, an alarm and/or a report code to be sent to the monitoring station.
  • Page 24: Programmable Outputs

    7.0 Programmable Outputs (PGMs) The MG-RCV3 comes equipped with four on-board PGM outputs. However, only PGMs 3 and 4 are used when connected to a Spectra or Digiplex series control panel. • PGM 1 and 2: Not used • PGM 3: Form “C” relay output rated at 5A/28Vdc, N.O./N.C •...
  • Page 25: Remote Control Programming

    Depending on the system being used, the MG-RCV3 supports up to 16 fully programmable remote controls without occupying any zones in the control panel. For Spectra systems, up to 8 remote controls can be assigned to a MG-RCV3. Digiplex series systems support up to 16 remote controls for every Magellan module.
  • Page 26: Assign A Remote Control To The Magellan Module

    [216] IGIPLEX SERIES SECTIONS Remote controls are assigned to the MG-RCV3 using the Automatic Learning method. For Spectra systems, up to eight remote controls can be assigned to a MG-RCV3. Depending on which Spectra control panel version you are using, the Automatic Learning method may differ.
  • Page 27: View The Assigned Remote Controls (Digiplex Series Only)

    IGIPLEX SERIES SECTIONS Each remote control that is assigned to the MG-RCV3 is given a remote control number (refer to Table 8.3 on page 28). The number of the assigned remote controls are viewed in sections [040] and [041]. This...
  • Page 28: Delete An Assigned Remote Control

    [040] [041] IGIPLEX SERIES SECTIONS Delete a remote control that has been assigned to the MG-RCV3. How to delete an assigned remote control: Spectra (V1.23 or lower) In step 3 in section 3.1 on page 8: 1. Enter a section number between [721] and [728].
  • Page 29: Assign A Remote Control To A User

    Digiplex Series In step 5 in section 3.2 on page 8: 1. Enter section [040] or [041]. 2. Press the button on the keypad that corresponds to the remote control that you wish to delete. For example, to delete the remote control assigned to section [201], press the [1] button in section [040] until the “1”...
  • Page 30: Program The Remote Control Buttons

    Digiplex Series Sections [301] to [316] represent the remote controls assigned in sections [201] to [216] respectively. For example, to assign the remote control that was assigned in section [201] to a user, enter the appropriate user number in section [301]. In step 5 in section 3.2 on page 8: 1.
  • Page 31 How to program the remote control buttons: Spectra Sections [711] to [718] represent the remote controls assigned in sections [721] to [728] or [731] to [738] (refer to section 8.1 on page 22). For example, the buttons for the remote control assigned in section [721]/[731] will be programmed in section [711].
  • Page 32: Remote Control Button Programming

    The User Code assigned to the remote control (refer to section 8.2 on page 25) must have the same options enabled as the remote control. For example, if you enable the Force Arming button option, you must enable the appropriate Force Arming user option in the control panel. Also, if you enable any Panic button options, you must enable the Panic options in the control panel (refer to the appropriate Reference &...
  • Page 33 Table 8.3: Remote Control Button Programming (cont’d) Digiplex RC Buttons Spectra Series (refer to Table 8.4 on page 30) Section Section Default: ( 1 5 0 0 0 0 0 0 ) _____/_____/_____/_____/_____/_____/_____/_____ [718] [408] _____/_____/_____/_____/_____/_____/_____/_____ [409] _____/_____/_____/_____/_____/_____/_____/_____ [410] _____/_____/_____/_____/_____/_____/_____/_____ [411] _____/_____/_____/_____/_____/_____/_____/_____ [412]...
  • Page 34: Remote Control Button Options

    Figure 8.1: Remote Control Button Programming Example In this example, the MG-RCV3 is connected to a DGP-NE96 control panel and the user is utilizing an LCD keypad. The button is programmed to Regular Arm, the button is programmed to Disarm, and the...
  • Page 35: Hexadecimal Values And Indicators

    = Utility Key 4* = Panic 1† (Police) = Utility Key 5* * Since the MG-RCV3’s PGMs are always enabled and are activated only with Magellan remote control buttons respectively (refer to section 7.2 on page 20), the PGM and Utility Key options pertain only to PGMs on other modules connected to the system.
  • Page 36: Spectra Hexadecimal Values & Indicators

    Table 8.5: Spectra Hexadecimal Values & Indicators Keypad Display Value or What Do I 10-Zone 16-Zone Action Press? 1 to 9 [1] to [9] [1] to [9] [1] to [9] [1] to [9] [0 (10)] [10] [11] STAY STAY [12] [13] ] / [ [14]...
  • Page 37: Delete Remote Control Button Programming

    8.3.2 Delete Remote Control Button Programming [711] [718] PECTRA SECTIONS [401] [416] IGIPLEX IGIPLEX SECTIONS How to delete a remote control’s button programming: Spectra Sections [711] to [718] represent the remote controls assigned in sections [721] to [728] or [731] to [738] (refer to section 8.1 on page 22).
  • Page 38: Programming Sections (Spectra)

    Section # Default Settings [001] Options 1 to 8 = OFF How to reset the MG-RCV3 when connected to a Digiplex series control panel: 1. Press and hold the [0] button. 2. Enter the [ ] (default=000000). INSTALLER CODE 3. Enter section [951] (DGP-848) or [4001] (DGP-NE96).
  • Page 39: Programming Sections (Digiplex Series)

    ON = manually Option [7]: PGM 4 deactivation mode OFF = deactivates after 2 seconds ON = manually Option [8]: Ignore transmitter tamper signal OFF = MG-RCV3 ignores tamper signal (default) ON = MG-RCV3 reports tamper signal Magellan Wireless Expansion Module...
  • Page 40 • View the number of remote controls assigned to the MG- RCV3 • Delete the assigned remote controls [101] to [116] • Assign the transmitters to the MG-RCV3 • Delete the assigned transmitters (000000) [201] to [216] Assign the remote controls to the MG-RCV3...
  • Page 41 Warranty Paradox Security Systems Ltd. (“Seller”) warrants its products to be free from defects in materials and workmanship under normal use for a period of one year. Except as specifically stated herein, all express or implied warranties whatsoever, statutory or otherwise, including without limitation, any implied warranty of merchantability and fitness for a particular purpose, are expressly excluded.
  • Page 42 Notes...
  • Page 44 780 Industriel Blvd., Saint-Eustache (Quebec) J7R 5V3 CANADA Tel.: (450)491-7444 Fax: (450) 491-2313 www.paradox.ca PRINTED IN CANADA 05/2005 MGRCV3SD-EI01...
