3.1 Connector Assignment

Table 2: Connector 1 Pin Assignment
Connector 1 (Top Side)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
The finger design of Connector 1 is match to either of the following card edge connector:
1. EDAC, CONN EDGE DUAL FMALE 36POS 0.100, P/N# 395-036-520-202 or,
2. SULLINS, CONN EDGE DUAL FMALE 36POS 0.100, P/N# EBC18DREH
The use of the above mentioned card edge connector is not needed if necessary connections can be made via manual
soldering to the relevant card edge fingers.
HEDS-9930
Label
CAL
ANA OUT
INDEX_SEL
SEL1
SEL2
SEL3
AGND/VSSA
VCC
VDD
DGND/VSSD
CH_A/A+
CH_A/A- (SPI_DIN)
CH_B/B+
CH_BB/B- (SPI_CLK)
CH_I/I+(SPI_DOUT)
CH_I/I- (CLK_100KHz)
NC
NC
