3.1 Connector Assignment

Table 3 : Connector 1 Pin Assignment
Connector 1 (Top Side)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
The finger design of Connector 1 is match to the following connectors:
1. EDAC, CONN EDGE DUAL FMALE 36POS 0.100, P/N# 395-036-520-202 or,
2. SULLINS, CONN EDGE DUAL FMALE 36POS 0.100, P/N# EBC18DREH
The use of the above mentioned card edge connector is not needed if necessary connections can be made via manual
soldering to the relevant card edge fingers.
Label
NC
NC
NC
NC
INDEX_P/I+
INDEX_P/I-
VSSA/AGND
VDDA/VCC
CH_A/A+
CH_AB/A-
VDD
VSSD/DGND
CH_B/B+
CH_BB/B-
NC
NC
NC
NC
