HEDS-9930PRGEVB User Guide

1.0 HEDS-9930EVB Evaluation Board

1.1 Top and Bottom Views

Mounting slot
Mounting hole
NOTE Please remove the protective kapton tape covering the encoder ASIC before use.
The silk screen printed guide line on the PCB is to help in providing visual alignment of the code wheel edge (outer
diameter) for each of the different Rop (CPR) tracks. A sample diagram showing the position when encoder is aligned to
625 CPR track is shown in Figure 3 below.
HEDS-9930
Figure 1 Bottom Side of the PCB
Code wheel OD
alignment guide
lines
Figure 2 Top Side of the PCB 397 LPI
Evaluation Board & Programming Kit
HEDS-9930PRGEVB _UG100
4
