2. Standard installation

7
3
Ref. Code
A
1 BOX3EH
2 ZEN
AXK4
AXK5M
AXK5N
3
AXK5NM
AXK5NI
AXR7
LIN2
LIN2B
4
AXP2
LAB4
5 LAB9
SOFAP20
6 SOF2M20-SOF3M20
SOFA15-SOFA20-SOFA25
FLM
FL24
7
4
5
Connect the power supply to a certified-compliant omnipolar switch (not included)
with a contact opening distance of at least 3mm. Connection to the mains must
be via an independent conduit, separated from the connections to the command
and safety devices.
Gearmotor
Transmitter
Digital combination wireless keypad
Wall-mounted key-operated selector switch with European cylinder
Semi-recessed key-operated selector switch with European cylinder
Wall-mounted key-operated selector switch without cylinder
Semi-recessed key-operated selector switch without cylinder
RFID reader unit
Photocells
Magnetic loop
Safety edge
Flashing light
Antenna (integrated in the flashing light)
30
1
6
2
Description
A
4
Cable
3G x 1.5 mm²
/
/
4 x 0.5 mm²
5 x 0.5 mm²
4 x 0.5 mm²
2 x 1,5 mm²
2 x 0,5 mm²
min
2 x 1 mm²
coax cable
RG-58 (50 Ω)
