Connection
Connect the OLED Pit Display (RLVBPITDSP) to the RS232 / CAN port on the Pit Lane Timer using the flying lead.
Configuration
IMPORTANT
For the OLED Pit Display to work correctly with a Pit Lane Timer, you must make sure that the CAN baud rate is the
same on both the
Pit Lane Timer
Display Menu
and the OLED Pit Display.
https://en.racelogic.support//Product_Info/Displays/OLED_Pit_Displays/RLVBPITDSP-V1/User_Guide_-
_OLED_Pit_Display_(VBPITDSP-V1)
2
