HP 2605dn Print Drivers System Administrator Manual page 146

Table 8-31
Color
Width
13. Click Add to map. The new label is automatically added to the image map.
14. To move the label to a location on the image map, click the label text box on the image map and
drag to the location.
15. Click a new printer on the image map to add more labels as necessary, or click Hide to close the
label panel.
NOTE: To remove a label, select the label in the Image map panel or in the Labels drop-down
menu. Then, click Remove label in the Labels panel.
List with printer graphics view
1. Click the option button next to List with printer graphics.
2. Optionally, select the Show device address check box to display the product address in the list
with the printer graphics view. (This box is not selected by default.)
3. Click one of the options listed in
specify the list format.
Table 8-32
Option
All printer groups on one page
Each printer group in its own frame
4. Click Preview to view the list with the selected options. A new browser window displays that
contains the list output.
5. Click Configure to make more changes to the list. The Configure list with printer graphics
screen displays.
6. On the Printer select menu, select a printer to include in the list.
7. Click Auto match images for all printers.
132 Chapter 8 Manage the HP UPD using HP Managed Printing Administration (HP MPA) and
Active Directory Group Policy
Labels panel options (continued)
Select one of the following color options from the menu to apply the color to
the label text. (Black is the default.)
●
●
●
●
Select one of the following options to set the width of the label text box. (The
200 pixels option is the default.)
●
●
●
Table 8-32 Graphics view—List format options on page 132
Graphics view—List format options
Description
Click this option to format the table with all printer groups on one page.
Click this option to format the table with one printer group per frame.
Black
Red
Blue
Green
100 pixels
200 pixels
300 pixels
to
ENWW
