Display Console - Sainlogic WS0355 User Manual

QTY

Display Console

Frame Dimensions :
7.56x4.76x0.79inch
1
(192x121x20mm)
LCD Dimensions:
6.7x3.1inch (171x78mm)
3.4 Display Console
3.4.1 Layout of Display Console
The following illustration shows display console features in
normal mode as below :
3.4.2 Setup the Display Console
1. Plug in the display console with power adapter. BL ON
will display in the time area for three seconds when powered
up.
Item
- 2 -
