SECTION 7
12-24V DC-DC
Regulator with relay
*Sales code: 1274REG0V0
NO
COM
RELAY CONTROL
0V / COM
+24V DC IN
FIGURE 86. ANTI-TAMPER ALARM WIRING WITH SIREN
Fuse
Max: 3A
OR
External
12V DC Lead
Acid Battery
and Charger
12V DC Siren
page 49
ELECTRICAL SETUP OF ACCESSORIES
Fuse
Max: 3A
External
24V DC Lead
Acid Battery
and Charger
24V DC Siren
SDO4 SMART
www.centsys.com
IO2
+24V
COM
SB
IO1
