3.1. Fasteners List and Spares

Description
ST5.5 x 50 Self-tapping Coach Screws
ST8 x 60 Self-tapping Screws
ST6.3 x 25 Self-tapping Screws
- Hex Flange Head
M6 x 8 Black Cross Pan Head Screws
M8 x 20 Hexagon Head Bolts
M6 x 12 Black Wizzlock Bolts

4. Required Tools and Equipment

Electric drill
Extension cord
QTY
4
3
3
2
6
4
Tin Snips
Drill bits
11mm & 6mm
masonry;
6mm drill bit
Description
M8 Wizzlock Nuts
Ø8 x 71 Clevice Pin
Ø8 x 18 Black Clevice Pin
Ø2 Hairpin Clips
12 x 60mm Fischer Plugs
M8 x 25(Pitch 1.25) Black Gutter Bolts
Screwdrivers
3.5mm flat;
No.2 Phillips
Measuring
2 Spirit levels
FIGURE 3. REQUIRED TOOLS AND EQUIPMENT
page 13
REQUIRED TOOLS AND EQUIPMENT
10mm, 12mm,
and 13mm
Sockets,
Socket wrench,
and extension
tape
10mm Coach
screws
(13mm hex head)
and plugs
Marking
pen/chalk/pencil
www.centsys.com
QTY
8
1
1
2
3
2
TABLE 3
