- Page 1 MODEL RTA-M101 ASSEMBLY INSTRUCTIONS Thank you for purchasing our product. REV.122020-1...
-
Page 2: Main Parts List
RTA-M101 MAIN PARTS LIST Backrest Seat 5-Leg star base Mechanism Hydraulic gas lift Casters Support for Covers for gas backrest with X1 Set lift accordion cover LIST OF HARDWARE PART ITEM USE IN M6x16 Mechanism to seat M6x25 Support to backrest Cover Support to backrest Metal bracket... - Page 3 RTA-M101 BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS. ❶ ❻ Do a quick inventory to Make sure you make sure the package understand which hardware contains all the parts and will be used on each step. hardware listed in the Using the wrong size of assembly instructions.
- Page 4 RTA-M101 ASSEMBLY STEPS STEP 1 Insert the casters F into the legs of the base C using pressure, then place the gas lift E in the middle of the base and cover it with H. STEP 2 First attach the metal The screws bracket 3B to the rod on go through 3A...
- Page 5 RTA-M101 STEP 4 Assemble the mechanism D to the seat B with screws 1. Hardware M6x16 (Front) STEP 5 Put the seat over the base parts making sure the tip of the gas lift E enters into the hole of the mechanism D.
-
Page 6: Care And Maintenance
RTA-M101 CHAIR’S FUNCTIONS To raise or lower the chair’s height, pull UP the lever that is under the seat. The chair goes down while sitting on it, or up if you lift your body. Please note that this chair does not recline. Weight Limit 150 Lbs... - Page 7 9.Report any defects to RTA Products, LLC together with your sales receipt or other proof of purchase. If the chair is defective within the terms of the warranty, RTA Products, LLC will furnish a replacement chair (at its option) at no cost of equal or similar value and design.
- Page 8 RTA-M101 FOR SEVERAL HELP OPTIONS INCLUDING REPLACEMENT PARTS ORDERS _________________________________________________________________ WWW.TECHNIMOBILI.COM VISIT: CLICK ON SUPPORT TAB Scan QR Code to order replacement parts SUPPORT@RTAPRODUCTS.COM OR EMAIL US:...
