- Page 1 MODEL RTA-7050 ASSEMBLY INSTRUCTIONS Thank you for purchasing our product. REV.122020-0...
- Page 2 RTA-7050 • Please read carefully the assembly instructions before the installation. • Do not discard this manual or any of the packaging material until the unit has been completely assembled. • Might require two people.
-
Page 3: Main Parts List
RTA-7050 MAIN PARTS LIST Top panel for upper section Short vertical Long exterior panel for upper vertical panel for section upper section Middle panel for upper section Long interior Bottom panel for Top panel for lower section vertical panel for upper section upper section Bottom panel for lower section... - Page 4 RTA-7050 LIST OF HARDWARE, SCREWS AND FITTINGS PART ITEM PART ITEM M6x35 ST3x14 ⌀8x30mm ⌀25 (felt) (wooden dowels) ⌀22 (laminate) ST7x58 ST3.5x40 MAIN PARTS LAYOUT (FOR REFERENCE): ❶ ❸ ❼ ❸ ❷ ⓮ ⓬ ⓮ ❽ ❹ ❺ ❾ ❻...
- Page 5 RTA-7050 ☛ This unit uses cam bolts and locks. The following explains how to use them. This is not an assembly step; it is a guide for when you are actually doing the assembly using this kind of hardware. Cam Bolt Cam Lock 1.
- Page 6 RTA-7050 BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS. ❼ To avoid ❶ Do a quick inventory misalignments, always to make sure the package leave the screws loose contains all the parts and and tighten them until hardware listed in the all pieces are assembly instructions.
- Page 7 RTA-7050 STEPS 1 THROUGH 11 IS FOR THE ASSEMBLY OF THE LOWER SECTION, WHICH WILL ASSEMBLE UPSIDE-DOWN STEP 1 Separate the sliders 19 according to their shape: - The “L” sliders (for the drawers) will be used until step 10, please set them aside.
- Page 8 RTA-7050 STEP 3 On the top panel 7 screw the bolts A into the outermost holes and insert Hardware: the wooden dowels B in the innermost holes as shown. Bolts: Outermost holes M6x35 Dowels: Innermost holes Φ8x30 STEP 4 With the panels 9, 10, 11 and 12 oriented upside-down, insert and Hardware: align the cam locks A into the panels, then slide down the panels over the bolts and dowels of panel 7, and turn the cam locks to secure all...
- Page 9 RTA-7050 STEP 6 First insert the dowels B in the innermost holes on panels 9, 10, 11 and Hardware: 12, then with the help of another person place the bottom panel 8 and assemble it to the panels using screws C as shown. Φ8x30 ST7x58 The groove on...
- Page 10 RTA-7050 STEP 9 Insert and align the cam locks A in the side panels 15 and 16. Then Hardware: screw the bolts A into panel 14, and assemble this panel to panels 15 and 16 as shown and as explained on page 4. Sets M6x35 Refer to page 4...
- Page 11 RTA-7050 P.10 P.10 STEPS 12 THROUGH 17 ARE FOR THE ASSEMBLY OF THE UPPER SECTION, WHICH WILL ALSO ASSEMBLE UPSIDE-DOWN STEP 12 1st: Insert the dowels B in the innermost holes on panel 1 on the center and right side. Hardware: 2nd: Insert the bolts A in the outermost holes on panel 1.
- Page 12 RTA-7050 P.11 P.11 STEP 14 1st: Insert the dowels B in the innermost holes on panels 1 and 3. Hardware: 2nd: Insert the bolts A in the outermost holes on panel 1. 3rd: Insert and align the cam locks A in panel 5. 4th: Assemble the panel 2 to the panels 3, and the panel 5 to the panel Sets 1 as shown and as explained in page 4.
- Page 13 RTA-7050 P.12 P.12 STEP 16 Insert the dowels B in the innermost holes on panels 4 and 5, then Hardware: assemble panel 6 using screws C. Φ8x30 ST7x58 STEP 17 Place the following adhesive stickers: Felt F on panel 6. Hardware: Laminate G for the cam lock holes on panels 3, 4 and 5.
- Page 14 RTA-7050 P.13 P.13 ALL DONE! Give yourself a nice pat on the back. You did a great job! You can place the upper section over the lower section according to your preference. The below illustrations show some suggestions. WARNING: For safety, when setting the unit in expanded option, do not place the upper section too close to the edge on the lower section.
- Page 15 RTA-7050 P.14 P.14 AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING CARE AND MAINTENANCE WARNINGS: WEIGHT LIMITS: = 55 Lbs. (25 Kg) expanded 88 Lbs. (40 Kg) closed = 88 Lbs. (40 Kg) = 44 Lbs. (20 Kg) = 11 Lbs.
- Page 16 RTA Products, LLC warrants to the Original Purchaser who acquired a new product from RTA Products or its authorized resellers that this product will be free from defects in its workmanship and materials, under normal use and service conditions, as described herein.
- Page 17 RTA-7050 P.16 P.16 FOR SEVERAL HELP OPTIONS INCLUDING REPLACEMENT PARTS ORDERS _________________________________________________________________ WWW.TECHNIMOBILI.COM VISIT: CLICK ON SUPPORT TAB Scan QR Code to order replacement parts SUPPORT@RTAPRODUCTS.COM OR EMAIL US:...
