Model No. SAE-C15X
Direct drive 2 post Lift
Single Point Manual Release
Lifting Capacity 15,000 lbs
mportant Note
I
1.
This equipment can not be installed, operated or repaired without reading instructions.
2.
Electricity must be hooked up by certified electrician.
3.
Do not use this equipment beyond its rated capacity.
Installation & Operation &
Maintenance Instructions
1
Advertisement
Table of Contents
Related Manuals for Stratus SAE-C15X
Summary of Contents for Stratus SAE-C15X
- Page 1 Model No. SAE-C15X Installation & Operation & Maintenance Instructions Direct drive 2 post Lift Single Point Manual Release Lifting Capacity 15,000 lbs mportant Note This equipment can not be installed, operated or repaired without reading instructions. Electricity must be hooked up by certified electrician.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Packing, transport and storage ..........................4 Packing ................................. 4 Transport ................................4 Storage .................................. 4 Technical specifications .............................. 5 Equipment plan ..............................6 Safety .................................... 7 Important notices ..............................7 Qualified personnel ............................. 7 Danger notices ..............................7 Training ................................ - Page 3 Operation and use ..............................20 Controls ................................20 Vehicle positioning ............................20 Lifting .................................. 20 Standing ................................21 Lowering ................................21 Maintenance................................22 Ordinary maintenance ............................22 Periodic maintenance ............................22 Troubleshooting ................................ 23 Parts list ..................................24 Main column and parts list ..........................24 Packing list .................................
-
Page 4: Packing, Transport And Storage
Packing, transport and storage All packing, lifting, handling, transport and unpacking operations are to be performed exclusively by expert personnel with knowledge of the lift and the contents of this manual. Packing The packing of the lift is delivered in following components: a.1 base unit packed in a steel frame, wrapped up in non-scratch material, including all the accessories. -
Page 5: Technical Specifications
Technical specifications Machine model SAE-C15X Lifting capacity 15,000lbs (6,800kg) Lifting Height 75.20"（1910MM） Minimum height 4.31"（110M） Lifting time About 50 sec Voltage 220V Frequency 60Hz power Hydraulic oil 46＃/68＃ ambient humidity 30-95% Machine noise < 76dB(A) Equipment weight... -
Page 6: Equipment Plan
Equipment plan Symmetric Installation... -
Page 7: Safety
Safety Important notices This ultra thin low lift is specially designed for lifting motor vehicles that weighs within its outmost lifting capacity. ➢ Users are not allowed to use it for any other purposes. Otherwise, we, as well as our sales agency, will not bear any responsibility for accidents or damages of the lift. -
Page 8: Training
Training Only these qualified people, who have been properly trained, can operate the lift. We are quite willing to provide ➢ professional training for the users when necessary. Attention: For environment protection, please dispose the disused oil in a proper way. ➢... -
Page 9: Installation
Installation ➢ Only skilled technicians, appointed by the manufacturer, or by authorized dealers, must be allowed to carry out installation. Serious damage to people and to the lift can be caused if installations are made by unskilled personnel ➢ Always refer to the exploded views attached during installation. Tool required Rotary Hammer Drill D.20 Carpenter’s Chalk... -
Page 10: Checking For Room Suitability
Checking for room suitability ➢ The lift has been designed to be used in covered and sheltered places free of overhead obstructions. The place of installation must not be next to washing areas, painting workbenches, solvent or varnish deposits. The ➢... -
Page 11: Site Layout
Site layout Now locate the lift according to the floor plan the figure 3, use a carpenters chalk line to layout a grid for the column ➢ locations. After the column locations are properly marked, use a chalk or crayon to make an outline of the columns on the floor ➢... -
Page 12: Assembly Diagram
Assembly diagram... -
Page 13: Assemble Columns
Assemble columns ➢ Assemble main column & extension column, and then stand up the 2 columns (the column with the power unit base plate is the main column and the other one is the vice column) Note: Don't drill anchor bolts holes or install anchor bolts now. ➢... -
Page 14: Installation Overhead Top Beam
Installation overhead top beam 1. Assemble overhead top beam. NOTE: The bolts run from inside of the column and then fasten the nuts from outside of the column. 2. Install the overhead beam cable pulley Warning: Symmetrical installation and asymmetrical installation of the cable pulley positions are not universal. In-correct installation of the pulley positions may cause damage to the cable or the lift. -
Page 15: Position Columns
Position columns ➢ Check if the columns are vertical to the ground with level, insert thin shims (come with package) to adjust when necessary... -
Page 16: Adjust Carriage
Adjust carriage 4.10 ➢ Raise the carriage to the 1st locking position located at the bottom of the column . Note: You can hear “click” once locked. Install cables (2 Cables in total ) 4.11 Routing the safety release cable 4.12 The safety lock has been pre-installed. -
Page 17: Installation Of Power Unit
Installation of power unit 4.13 Attach the power unit onto the bracket ; Secure it using nuts M10X20, the locking washers D.10 and washers D. Mount the bracket with the power unit on the column with screw M8X16 Connection of hydraulic hoses 4.14 Connect the longer hose in between the 2 cylinders, connect the short hose in between the cylinder and the power unit. -
Page 18: Oil Filling And Bleeding
Oil filling and bleeding 4.16 DO NOT run power unit without oil. Damage to pump can occur. If motor gets hot or sounds peculiar, stop immediately and recheck the electric connection. If the vented cap is lost or broken, order the replacement. The oil tank must be vented well. Add about 2.5 gallons of hydraulic oil to the hydraulic fluid reservoir, AW32 during winter time (cold weather), and AW46 during summer time (hot weather). -
Page 19: Check Before Start-Up
Check before start-up General checks Make sure that the columns are plumb; Make sure the lift anchored to the ground and all anchor bolts tightened. Make sure the electrical system feeding voltage is equal to that specified in the nameplate on the motor; Make sure the electric system connection in conformity of the electric plan shown as the electric diagram and for proper grounding. -
Page 20: Operation And Use
Operation and use NEVER operate the lift with any person or equipment below. NEVER exceed the rate lifting capacity. NEVER lift a vehicle in any manner with less than four arms. Always ensure that the mechanical locks are engaged before any attempt is made to work on or near the vehicle. Always lift a vehicle on the lifting pads. -
Page 21: Standing
Standing Press the lowering lever to engage the nearest lock position; Always ensure that the lock in each column is engaged before any attempt is made to work on or near the vehicle. Lowering Raise the lift a little bit by pushing the lifting button to clear off the mechanical locks; Release the locks manually;... -
Page 22: Maintenance
Maintenance Only trained people who know how the lift works, can be allowed to service the lift. To service properly the lift, the following has to be carried out: use only genuine spare parts as well as equipment suitable for the work required; follow the scheduled maintenance and check periods shown in the manual;... -
Page 23: Troubleshooting
Troubleshooting Troubleshooting and possible maintenance require all safety precautions specified in the absolute instructions. Problem Possible cause Solution The lift does non rise Burnt fuse Replace fuse Connect again when the pushbutton is Line current does not arrive Malfunction pressed Call Service Center in the electric plant: (motor does not run) -
Page 24: Parts List
Parts list Main column and parts list... -
Page 28: Packing List
Packing list Special notes Environmental damage 10.1 Only appropriately trained personnel may dismantle and dispose of the unit. Dismantling 10.2 To dismantle the product, proceed as follows: ELECTRICAL HAZARD! When carrying out any decommissioning and dismantling work on the unit, switch off all power supply connections, ensure they cannot be switched on unintentionally and verify that they have been disconnected. -
Page 29: Disposal
It is important that all transport information is observed . Disposal 10.3 A specialist company with the appropriate competence must dispose of the unit and individual components. This technical services department must ensure that: the components are separated according to material types that the operating materials are sorted and separated according to their properties.
