Model No. SAE-C9P
Two Post Lift，
Manual Release
Lifting Capacity 9000 lbs.
Important Note
1. This equipment cannot be installed, operated or repaired without reading instructions.
2. Electricity must be hooked up by certified electrician.
3. Do not use this equipment beyond its rated capacity.
Installation, Operation
and Parts Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stratus SAE-C9P
Summary of Contents for Stratus SAE-C9P
- Page 1 Model No. SAE-C9P Installation, Operation Two Post Lift， and Parts Manual Manual Release Lifting Capacity 9000 lbs. Important Note 1. This equipment cannot be installed, operated or repaired without reading instructions. 2. Electricity must be hooked up by certified electrician.
-
Page 2: Table Of Contents
Installation, Operation and Parts Manual SAE-C9P SAFETY NOTES ..............................3 1.1 Operation of lifting platforms ..........................3 1.2 Checking of the lifting platforms ..........................3 1.3 Important safety notices ............................4 1.4 Warning labels ............................... 5 1.5 Potential safety risks .............................. 6 1.6 Noise level ................................ -
Page 3: Safety Notes
Installation, Operation and Parts Manual SAE-C9P SAFETY NOTES 1.1 Operation of lifting platforms This lift is specially designed for lifting motor vehicles. Users are not allowed to use it for any other purposes. The applicable national regulations, laws and directives must be observed. -
Page 4: Important Safety Notices
Installation, Operation and Parts Manual SAE-C9P engineering to be able to check and give an expert option on lifting platforms. 1.3 Important safety notices 1.3.1 Recommend for indoor use only. DO not expose the lift to rain, snow or excessive moisture. -
Page 5: Warning Labels
Installation, Operation and Parts Manual SAE-C9P 1.4 Warning labels All safety warning labels are clearly depicted on the lift to ensure that the operator is aware of and avoid the dangers of using the lift in an incorrect manner. The labels must be kept clean and they have to be replaced if detached or damaged. Please read carefully the meaning... -
Page 6: Potential Safety Risks
Installation, Operation and Parts Manual SAE-C9P 1.5 Potential safety risks 1.5.1 Mains voltage nsulation damage and other faults may result in accessible components being live Safety measures: Only ever use the power cord provided or a tested power cord. -
Page 7: Packing, Storage And Transportation
Installation, Operation and Parts Manual SAE-C9P PACKING, STORAGE AND TRANSPORTATION Packing, lifting, handling, transporting operations must be performed only by experienced personnel with appropriate knowledge of the lift and after reading this manual. 2.1 The lift was dismantled into the following 2 parts for transportation... -
Page 8: Products Descriptions
Installation, Operation and Parts Manual SAE-C9P PRODUCTS DESCRIPTIONS 3.1 General descriptions This is chassis supporting vehicle lift for road vehicles. It is mainly composed by two posts, two carriages, four swing arms and a power and control unit. It is driven by an electro-hydraulic system. The gear pump delivers hydraulic oil to oil cylinders and pushes upwards its piston. The cylinder piston drives to raise the carriage and swing arms. -
Page 9: Dimensions
Installation, Operation and Parts Manual SAE-C9P 3.4 Dimensions... -
Page 10: Safety Devices Descriptions
Installation, Operation and Parts Manual SAE-C9P 3.5 Safety devices descriptions POS. Description Function Roof protective limit switch Stop rising in case the overhead bar is touched. Max rise limit switch Stop rising at max height. Mechanical safety locking unit Catch the carriages in case of hydraulic failure. -
Page 11: Installation Instructions
Installation, Operation and Parts Manual SAE-C9P INSTALLATION INSTRUCTIONS 4.1 Preparations before installation 4.1.1 Space requirements. Refer to 3.4 for the dimensions of the lift. There must also be a clearance of at least 1 meter between the lifting platform and fixed elements (e.g. -
Page 12: General Installation Steps
Installation, Operation and Parts Manual SAE-C9P 4.3 General installation steps ONLY TRAINED AND QUALIFIED INSTALLERS CAN PERFORM LIFT INSTALLATION DUTIES. Step 1: Remove the packaging and take out the accessories attached. ： Attention The packs must be opened adopting all the precautions required to avoid injury to persons (keep at a safe distance when cutting the straps) or damage to parts of the machine (be careful that no parts are dropped while you are opening the packing). - Page 13 Installation, Operation and Parts Manual SAE-C9P Step 4: Erect and secure the post. 1. Make the posts face to each other and the distance between the posts equals to the length of the crossbeam. Use proper means to erect the post.
- Page 14 Installation, Operation and Parts Manual SAE-C9P 1. Hex nut M14 6.Hex socket cylinder head screw M6x30 2.Flat washer M14 7.Hex nut M6 3.Spring washer M14 8.Protective rod 4.Hex head full swivel screw M14x30 9.Extending post 5.Crossbeam Step 6: Connect the synchronization steel cable.
- Page 15 Installation, Operation and Parts Manual SAE-C9P Step 7: Connect the hydraulic system. 1. Install hydraulic power unit onto the power side post. 1.Hex head flange screw M8x30 2.Anti-vibration pad 3.Hex head flange nut M8 4.Hydraulic power unit 2. Connect oil hoses to the three way connector in the power side post.
- Page 16 Installation, Operation and Parts Manual SAE-C9P Step 8: Make the electrical connection. ONLY qualified electricians are permitted doing the electrical connection. Read the name plate and check that the supply voltage is adapted to the voltage of the lift. Refer to Annex 2 before doing the connection.
- Page 17 Installation, Operation and Parts Manual SAE-C9P Step 9: Assemble and fix the mechanical safety locking unit. a. Assemble the locking device. Locking assembly at the power-side post 1.circlip 2.washer Locking assembly at the other post 3.spring 1 4.spring 2 5.shaft 6.handle bar...
- Page 18 Installation, Operation and Parts Manual SAE-C9P 2. Route and fix the release rope for mechanical safety locking assembly. 2.1 Make release rope goes through pulleys on top of the two posts and fix the release rope at both sides of the post.
- Page 19 Installation, Operation and Parts Manual SAE-C9P Step 11: Fill with hydraulic oil. ONLY CLEAN AND FRESH OIL ONLY Lift must be fully lowered before changing or adding hydraulic oil. Prepare 12 liters anti-abrasion hydraulic oil. Fill about 10 liters into the oil tank to run the lift up and down for 2 or 3times after the electrical system is connected.
- Page 20 Installation, Operation and Parts Manual SAE-C9P Step 13: Fix the protective column curtain. 1.Hex nut M6 2.Class C flat washer M6 3.Hook 4. Column curtain. 5. Cross socket cap head screw M6x8 Step 14: Install the height adapter holder. (Optional) 1.Height adapter...
-
Page 21: Items To Be Checked After Installation
Installation, Operation and Parts Manual SAE-C9P 4.4 Items to be checked after installation Check items √ Screw torque of expansion bolts : 80-100Nm; √ Rising speed ≥20mm/s; √ Noise with rated load ≤75dB(A); √ Grounding resistance: not bigger than 4Ω;... -
Page 22: Operation Instructions
Installation, Operation and Parts Manual SAE-C9P 5.2 Operation instructions Only one operator is allowed to work around the vehicle lift. Always engage the safety locking mechanism before any operation on the lifted vehicle. Do not make any operation on the lifted vehicle at a height under the first latching position (less than 500mm). -
Page 23: Trouble Shooting
Installation, Operation and Parts Manual SAE-C9P TROUBLE SHOOTING ATTENTION: If the trouble could not be fixed by yourself, please do not hesitate to contact us for help. We will offer our service at the earliest time we can. Troubles could be judged and solved much faster when more details or pictures could be provided. -
Page 24: Inspection And Maintenance
Installation, Operation and Parts Manual SAE-C9P INSPECTION AND MAINTENANCE Easy and low cost routine inspection and maintenance can ensure the lift work normally and safely. Follow the below routine inspection and maintenance schedule with reference to the actual working condition and frequency of your lift. - Page 25 Installation, Operation and Parts Manual SAE-C9P Components Methods Period Use proper means to activate the switch and push UP button to Roof protection limit switch every 30 days check if the carriage stop rising Check if mechanical locking hooks can engage or disengage...
-
Page 26: Annex 1, Floor Plan
Installation, Operation and Parts Manual SAE-C9P Annex 1, Floor plan Indoor installation only. There must also be a clearance of at least 1 meter between the lifting platform and fixed elements (e.g. wall) in all lifting positions. There must be sufficient space for driving vehicles on and off. -
Page 27: Annex 2, Electrical Schemes And Parts List
Installation, Operation and Parts Manual SAE-C9P Annex 2, Electrical schemes and parts list POS. CODE Descriptions 320301011 Limit switch 320301002 Limit switch... - Page 28 Installation, Operation and Parts Manual SAE-C9P 1Ph wire connection Wire L is going to be fixed with terminals A1, 3L2 and 1L1. Wire N is going to be fixed with terminals 5L3 and 13NO. Wire U is going to be fixed with terminals 2T1 and 4T2. Wire W is going to be fixed with terminals 6T3 and 14NO.
-
Page 29: Annex 3, Hydraulic Schemes And Parts List
Installation, Operation and Parts Manual SAE-C9P Annex 3, Hydraulic schemes and parts list 1.oil tank 2.oil sucking filter 3.gear pump 4.coupling 5.motor 6.hydraulic block 7.cushion valve 8.overflow valve 9.single way valve 10.manual unloading valve 11.flow control valve 12.oil tank cover 13.composite hydraulic block... - Page 30 Installation, Operation and Parts Manual SAE-C9P POS. CODE Descriptions Specification 622034300 Power unit 220V-60HZ-1PH-2.5KW-17MPA-10L 207103025 Composite washer 13_7X20X1_5 Composite connector 615015003 M14*1.5-G1/4 624008106 Rubber oil hose L=430mm 615006003 Three-way connector 6214E-A4-B4(6214A-A5-B2) Rubber oil hose 624008108 L=9460mm Rubber oil hose 624008104...
-
Page 31: Annex 4, Mechanical Exploded Drawings And Parts List
Installation, Operation and Parts Manual SAE-C9P Annex 4, Mechanical exploded drawings and parts list POS. Code Description Specification 615006015 Steel cable Φ9.3，L=10280mm 203101009 Hex nut M16-GB6170 204101009 Flat washer D16-GB95 410902109 Pulley C9Z-A1-B2... - Page 32 Installation, Operation and Parts Manual SAE-C9P POS. Code Description Specification Power unit 624008106 Oil hose L=430mm 624008104 L=1270mm Oil hose 615015003 6255E-A7-B7 Composite connector 207103025 13_7X20X1_5 Composite washer 615006003 6214E-A4-B4 Three way connector 624008108 L=9460mm Oil hose 615017013 Cylinder 6264-A24...
- Page 33 Installation, Operation and Parts Manual SAE-C9P POS. Code Description Specification 410902013 Spring C9Z-A1-B10 410902014 Spring C9Z-A1-B11 410010031 Washer 6254E-A1-B3 204301009 Circlip D25-GB894_2 410902031 Shaft C9Z-A1-B6 202111033 Hex socket flat head screw M8x65-GB70_3 202109005 Hex cylinder head screw M4X6-GB70_1 203101005 Hex nut...
- Page 34 Installation, Operation and Parts Manual SAE-C9P POS. Code Description Specification 208110003 Steel rope C10Z-A17 POS. Code Description Specification 614901418 Crossbeam (outside) C9MV2-A21-B1 202109024 Hex socket cylinder head screw M6X35-GB70_1 203103005 Locking nut M6-GB889_1 204101008 Flat washer D14-GB95 204201007 Spring washer...
- Page 35 Installation, Operation and Parts Manual SAE-C9P POS. Code Description Specification 203103005 Locking nut M6-GB889_1 410170101B Cylinder orientation ring 6264-A24-B1 202109096 Hex socket cylinder head screw M6X40-GB70_1 614901378 Carriage C9Z-A3-B1-2 420680083 Sliding block C9Z-A3-B5 420040160 Protective rubber pad 6254E-A2-B6 202111004 Hex socket flat head screw...
- Page 36 Installation, Operation and Parts Manual SAE-C9P POS. Code Description Specification 204101008 Flat washer D14-GB95 204201007 Spring washer D14-GB93 203101008 Hex nut M14-GB6170 201102035 Hex head full swivel screw M14X30-GB5783 614901416 Extending post for power side post C9MV2-A5-B1...
- Page 37 Installation, Operation and Parts Manual SAE-C9P POS. Code Description Specification 614901486 Power side post C9MV2-A1-B1-1 420680096 Protective cover C9Z-A1-B9-1 202109017 Hex socket cylinder head screw M6X8-GB70_1 203204103 M8-GB6177 Flange nut 420040010 6254E-A23 Anti-shock ring 201101103 M8X30-GB12 Cup head square neck bolts 202109085 Hex socket cylinder head screw (12.9)
