DEMO MANUAL DC2798A
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 4 C1, C85-C87
2 3 C3, C105, C120
3 2 C9, C23
4 10 C10-C12, C24-C26, C88,
C93, C122, C123
5 2 C13, C28
6 1 C18
7 1 C20
8 2 C71, C77
9 4 C94, C95, C115, C116
10 1 C104
11 2 C106, C117
12 8 C107-C114
13 1 C118
14 1 C119
15 1 C121
16 1 C124
17 2 C125, C126
18 2 D1, D2
19 1 D5
20 2 L1, L2
21 4 Q1, Q2, Q5, Q6
22 4 Q3, Q4, Q7, Q8
23 3 R13, R15, R194
24 2 R14, R37
25 2 R21, R44
26 2 R90, R92
27 1 R183
28 1 R185
29 3 R192, R198, R199
30 1 R193
31 1 R200
32 1 R201
33 1 R202
34 1 U1
8
PART DESCRIPTION
CAP ., 470µF, ALUM POLY HYB, 25V, 20%, 10x10.2mm, G,
SMD, RADIAL, AEC-Q200
CAP ., 4.7µF, X5R, 25V, 10%, 0603
CAP ., 0.22µF, X7R, 25V, 10%, 0603
CAP ., 10µF, X7R, 63V, 10%, 1210
CAP ., 0.01µF, X7R, 16V, 10%, 0603
CAP ., 0.01µF, X7R, 25V, 10%, 0603, AEC-Q200
CAP ., 100pF, C0G/NP0, 50V, 5%, 0603
CAP ., 1000pF, C0G, 100V, 5%, 0805
CAP ., 22µF, X7R, 25V, 10%, 1210
CAP ., 470pF, X7R, 50V, 10%, 0603
CAP ., 0.1µF, X7R, 100V, 10%, 0603
CAP ., 68µF, ALUM POLY HYB, 63V, 20%, 10x10.2mm, G, SMD,
RADIAL, AEC-Q200
CAP ., 120pF, C0G/NPO, 100V, 5%, 0603
CAP ., 1000pF, X7R, 16V, 10%, 0603
CAP ., 390pF, COG/NPO, 50V, 5%, 0603
CAP ., 2.2µF, X7S, 16V, 10%, 0603, AEC-Q200
CAP ., 1µF, X7S, 100V, 10%, 0805
DIODE, SCHOTTKY, 100V, 1A, POWERDI-123
DIODE, ZENER, 6.8V, 400mW, SOD-323
IND., 6.8µH, POWER SHIELDED WIREWOUND, 10%, 30A,
0.00205Ω, 27.9mm x 27.94mm
XSTR., MOSFET, N-CH, 60V, 64A, PG-TDSON-8
XSTR., MOSFET, N-CH, 60V, 100A, PG-TDSON-8
RES., 10k, 1%, 1/10W, 0603
RES., 0.002Ω, 1%, 3W, 2512, METAL, SENSE, AEC-Q200
RES., 100Ω, 1%, 1/10W, 0603, AEC-Q200
RES., 1.0Ω, 5%, 1/2W, 0805
RES., 5.1k, 1%, 1/10W, 0603, AEC-Q200
RES., 470k, 1%, 210mW, 0805, NTC THERMISTOR, AEC-Q200 VISHAY, NTCS0805E3474FXT
RES., 100k, 1%, 1/10W, 0603, AEC-Q200
RES., 191k, 1%, 1/10W, 0603
RES., 30k, 1%, 1/10W, 0603, AEC-Q200
RES., 38.3k, 1%, 1/10W, 0603, AEC-Q200
RES., 150k, 1%, 1/10W, 0603
IC, POWER CONTROLLER, QFN-36 (5x6)
MANUFACTURER/PART NUMBER
PANASONIC, EEHZK1E471P
MURATA, GRM188R61E475KE15D
MURATA, GRM188R71E224KA88D
SAMSUNG, CL32B106KMVNNWE
AVX, 0603YC103KAT2A
AVX, 06033C103K4Z2A
AVX, 06035A101JAT2A
TDK, C2012C0G2A102J060AA
SAMSUNG, CL32B226KAJNNNE
AVX, 06035C471KAT2A
AVX, 06031C104KAT2A
PANASONIC, EEHZC1J680P
AVX, 06031A121JAT2A
WURTH ELEKTRONIK, 885012206034
AVX, 06035A391JAT2A
TDK, CGA3E1X7S1C225K080AC
MURATA, GRJ21BC72A105KE11L
DIODES INC., DFLS1100-7
NEXPERIA, PDZ6.8B, 115
COILCRAFT, SER2915H-682KL
INFINEON, BSC065N06LS5
INFINEON, BSC027N06LS5
VISHAY, CRCW060310K0FKEC
PANASONIC, ERJMS4SF2M0U
PANASONIC, ERJ3EKF1000V
PANASONIC, ERJ6DQJ1R0V
NIC, NRC06F5101TRF
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW0603191KFKEA
KOA SPEER, RK73H1JTTD3002F
NIC, NRC06F3832TRF
PANASONIC, ERJ3EKF1503V
ANALOG DEVICES., LTC7841EUHE#PBF
