CRUSADER MASTER FUEL PRESSURE SPECIFICATIONS - 2013
MODEL
Fuel Pressure FCC
Fuel Pressure - FCC
Returnless Fuel System
w/mounted LPFP
Fuel Pressure mounted
LPFP
IMPORTANT: FUEL PRESSURE MEASUREMENT MUST BE MADE WITH THE ENGINE UNDER LOAD.
CRUSADER MASTER WARNING/ALARM SPECIFICATIONS - 2013
MODEL
Coolant
Over-Temperature
Sensor
Exhaust Manifold
Water Temperature
Sensors
(CES Applications
ONLY)
Transmission
Over-Temperature
Switch
Low Oil
Pressure Sensor or
(Switch-5.7L carb only)
NOTE:
FOR NEW BOAT PROPPING, IT IS RECOMMENDED THAT OEMS PROP TO THE MAXIMUM RPM LISTED.
MP 5.0L
57-62 psi @ WOT
57-62 psi @ WOT
7 - 9 psi
(WOT)
MP 5.0L
200°F
DTC 116/217
Check Gauges Lamp Check Gauges Lamp Check Gauges Lamp
and Buzzer
Engine Derates
N/A
235° F ± 10° F
DTC 1542
Check Gauges Lamp Check Gauges Lamp Check Gauges Lamp
< 5 psi @ idle /
< 24 psi @ 4000
M.I.L. - DTC 524
Check Gauges Lamp Check Gauges Lamp Check Gauges Lamp
and Buzzer
L510001-13
ENGINE SPECIFICATIONS - 12
MP 5.7L
57-62 psi @ WOT
57-62 psi @ WOT
7 - 9 psi
(WOT)
MP 5.7L
200°F
DTC 116/217
and Buzzer
Engine Derates
N/A
235° F ± 10° F
DTC 1542
< 5 psi @ idle /
< 24 psi @ 4000
M.I.L. - DTC 524
and Buzzer
MP 6.0L
59-62 psi @ WOT
66-69 psi @ WOT
7 - 9 psi
(WOT)
MP 6.0L
200°F
DTC 116/217
and Buzzer
Engine Derates
240°F
DTC 1415/1416/
1417/1418
Check Gauges Lamp
and Buzzer
Engine Derates
235° F ± 10° F
DTC 1542
< 5 psi @ idle /
< 24 psi @ 4000
M.I.L. - DTC 524
and Buzzer
